Technical Product Specification

iii
Board Identification Information
Basic Desktop Board DH61BE Identification Information
AA Revision
BIOS Revision
Notes
G14062-209 BEH6110H.86A.0041 1,2
G14062-210 BEH6110H.86A.0041 1,2
G14062-211 BEH6110H.86A.0044 1,2
G14063-204 BEH6110H.86A.0016 1,2
G14063-209 BEH6110H.86A.0041 1,2
G14063-210 BEH6110H.86A.0041 1,2
G14063-211 BEH6110H.86A.0044 1,2
Notes:
1. The AA number is found on a small label on the component side of the board.
2. The H61 chipset used on this AA revision consists of the following component:
Device Stepping S-Spec Numbers
82H61 B3
SLJ4B
Specification Changes or Clarifications
The table below indicates the Specification Changes or Specification Clarifications that
apply to the Intel
®
Desktop Board DH61BE.
Specification Changes or Clarifications
Date Type of Change Description of Change or Clarification
May 2011 Spec Clarifications
• The Intel H61 Express Chipset does not support RAID.
The following sections of this manual have been updated:
― Reference to RAID in Table 1. Feature Summary has
been deleted
― Section 1.9.1.1 Serial ATA RAID has been deleted
― Section 1.9.1.2 Intel
®
Rapid Recover Technology has
been deleted
― The Caution in Section 3.1 Introduction has been
deleted
• The maximum memory supported changed from 16 GB to
8 GB in the following sections of this manual:
― Table 1. Feature Summary
― Section 1.6 System Memory
― Section 2.1.1 Addressable Memory
― Figure 8. Detailed System Memory Address Map
• The two SATA 6 Gb/s ports are through the Marvell
88SE971X controller. The following sections have been
updated to reflect this:
― Table 1. Feature Summary
― Section 1.9 SATA Interfaces
March 2012 Spec Clarification Updated maximum memory supported from 8 GB to 16 GB
