Intel Desktop Board DH61BE Technical Product Specification
14
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1
Description
A Conventional PCI bus add-in card connector
B PCI Express x1 add-in card connector
C Chassis intrusion header
D S/PDIF header
E PCI Express x1 add-in card connector
F Battery
G PCI Express x16 add-in card connector
H Back panel connectors
I Front panel USB 2.0 header
J Standby power LED
K 12 V internal power connector (ATX12V)
L Rear chassis fan header
M Piezoelectric speaker
N LGA1155 processor socket
O Processor fan header
P Front chassis fan header
Q Low Pin Count (LPC) Debug header
R DIMM 1 (Channel A DIMM 1)
S DIMM 2 (Channel B DIMM 1)
T Trusted Platform Module (TPM) header
U Main power connector (2 x 12)
V SATA connectors (two 6 Gb/s SATA ports (blue) and four 3 Gb/s SATA ports
(black))
W BIOS setup configuration jumper block
X Front panel header
Y Alternate front panel power LED header
Z Intel
®
Management Engine BIOS Extension (Intel
®
MEBX) Reset header
AA Intel H61 Express Chipset
BB Serial port header
CC Front panel USB 2.0 headers (3)
DD Internal mono speaker header
EE Front panel audio header
