Intel Desktop Board DG965SS Technical Product Specification

Table Of Contents

Table 17. High Definition Audio Link Header

Pin Signal Name Pin Signal Name

1 BCLK 2 Ground

3 RST 4 3.3 V/1.5 V I/O

5 SYNC 6 Ground

7 SDO 8 3.3V_CORE

9 SDI 10 +12 V

11 No connect 12 Key (no pin)

13 No connect 14 3.3 V/1.5V STBY

15 No connect 16 Ground

Table 18. Serial ATA Connectors

Pin Signal Name

1 Ground

2 TXP

3 TXN

4 Ground

5 RXN

6 RXP

7 Ground

Table 19. Chassis Intrusion Header

Pin Signal Name

1 Intruder

2 Ground

Table 20. Serial Port Header

Pin Signal Name Pin Signal Name

1 DCD 2 RXD#

3 TXD# 4 DTR

5 Ground 6 DSR

7 RTS 8 CTS

9 RI 10 Key (no pin)
