Intel Desktop Board DG965SS Technical Product Specification

Technical Reference
51
Table 16 lists the component-side connectors and headers identified in Figure 16.
Table 16. Component-side Connectors and Headers Shown in
Figure 16
Item/callout
from
Figure 16 Description
A IEEE-1394a front panel header
B Front panel audio header
C PCI Conventional bus add-in card connector 1
D PCI Express x1 connector
E PCI Express x16 connector
F Processor core power connector
G Rear chassis fan header
H Processor fan header
I Serial port header
J Diskette drive connector
K Main Power connector
L Front chassis fan header
M Chassis intrusion header
N Auxiliary front panel power LED header
O Front panel header
P Serial ATA connectors [4]
Q Front panel USB header
R Front panel USB header
S Parallel ATE IDE connector
T PCI Conventional bus add-in card connector 2
U High Definition Audio header
