Product Description
11
Table 1. Feature Summary (continued)
Expansion
Capabilities
• Two PCI Conventional* bus connectors
• One PCI Express x1 bus add-in card connector
• One PCI Express x16 bus add-in card connector
Hardware Monitor
Subsystem
• Intel
®
Quiet System Technology implemented through ICH8
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Three fan headers
• Three fan sense inputs used to monitor fan activity
For information about Refer to
Available configurations for the Desktop Board DG965SS Section 1.2, page 15
