Intel Desktop Board DG41TY Specification Update

Intel Desktop Board DG41TY Specification Update 5
Terminology
Specification Changes are modifications to the current published specifications.
These changes will be incorporated in the next release of the specifications.
Errata are design defects or errors. Characterized errata may cause the desktop
board behavior to deviate from published specifications. Hardware and software
designed to be used with any given Altered Assembly (AA) and BIOS revision level
must assume that all errata documented for that AA and BIOS revision level are
present on all desktop boards.
Specification Clarifications describe a specification in greater detail or further
highlight a specification’s impact to a complex design situation. These clarifications
will be incorporated in the next release of the specifications.
Documentation Changes include typos, errors, or omissions from the current
published specifications. These changes will be incorporated in the next release of the
specifications.
General Information
Basic Desktop Board DG41TY Identification Information
AA Revision BIOS Revision Notes
E47335-202 TYG4110.86A.0016 1,2
E47335-203 TYG4110.86A.0024 1,2
E47335-300 TYG4110.86A.0031 1,2
E47335-301 TYG4110.86A.0036 1,2
E47335-302 TYG4110.86A.0036 1,2
E47336-300 TYG4110.86A.0031 1,2
E47336-301 TYG4110.86A.0036 1,2
E47336-302 TYG4110.86A.0036 1,2
Notes:
1. The AA number is found on a small label on the component side of the board.
2. The G41 Chipset kit used on this AA revision consists of two components as follows:
Device Stepping S-Spec Numbers
82G41 A3 SLB8D
82801GB A1 SL8FX
