Product Description
23
Table 6. Multiple Display Configuration Maximum Resolutions
Single Display
HDMI
Dual Display
DisplayPort and HDMI
Single Display
DisplayPort
1920 x 1200 @ 60 Hz 3840 x 2160 @ 60 Hz (DisplayPort)
1920 x 1200 @ 60 Hz (HDMI)
3840 x 2160 @ 60 Hz
4096 x 2304 @ 24Hz 3840 x 2160 @ 30 Hz (DisplayPort)
3840 x 2160 @ 30 Hz (HDMI)
Same as above
Note: Higher resolutions may be achievable but only at lower refresh rates
For information about
Refer to
Multiple display maximum
resolutions
https://www-
ssl.intel.com/content/www/us/en/processors/core/CoreTechnicalResources.html
(Generic link)
TBD (Specific Link)
1.5.1.6 High-bandwidth Digital Content Protection (HDCP)
HDCP is the technology for protecting high definition content against unauthorized copy or
interception between a source (computer, digital set top boxes, etc.) and the sink (panels, monitor,
and TVs). The PCH supports HDCP 1.4a for content protection over wired displays (Mini
DisplayPort and Mini HDMI).
1.5.1.7 Integrated Audio Provided by the Mini HDMI and
Mini DisplayPort Interfaces
The Mini HDMI and Mini DisplayPort interfaces from the PCH support audio. The processor
supports two High Definition audio streams on two digital ports simultaneously.
Table 7 shows the specific audio technologies supported by the PCH.
Table 7. Audio Formats Supported by the Mini HDMI and
Mini DisplayPort Interfaces
Audio Formats Mini HDMI Mini DisplayPort
AC-3 – Dolby* Digital Yes Yes
Dolby Digital Plus Yes Yes
DTS-HD* Yes Yes
LPCM, 192 kHz/24 bit, 8 channel Yes Yes
Dolby True HD, DTS-HD Master Audio* (Lossless Blu-ray Disc Audio
Format)
Yes Yes
