Intel NUC Board NUC5i5RYB and Intel NUC Board NUC5i3RYB Technical Product Specification
16
Table 3. Components Shown in Figure 2
Item from
Figure 2
Description
A Back panel connectors
B Auxiliary power connector
C Front panel header
D Intel Dual Band Wireless AC + Bluetooth 7265 module
E SATA power connector (1.25 mm pitch)
F M.2 connector (key type M) for 2242, 2260, and 2280 modules
G Front panel dual-port USB 2.0 header (1.25 mm pitch)
H Front panel USB 3.0 connector (blue)
I Front panel USB 3.0 connector (orange, charging)
J SATA 6.0 Gb/s connector
K Front panel stereo microphone/headphone jack
L Consumer Infrared (CIR) sensor
M Near Field Communications (NFC) Vertical Flexible Printed Circuit connector
N BIOS security jumper
O DDR3L SO-DIMM 1 socket
P DDR3L SO-DIMM 2 socket
