Regulatory Compliance and Battery Disposal Information
73
5.1.5 Regulatory Compliance Marks (Board Level)
Intel NUC Board NUC5i5RYB and Intel NUC Board NUC5i3RYB have the regulatory compliance
marks shown in Table 32.
Table 32. Regulatory Compliance Marks
Description
Mark
UL joint US/Canada Recognized Component mark. Includes adjacent UL file number
for Intel NUC: E210882.
FCC Declaration of Conformity logo mark for Class B equipment.
CE mark. Declaring compliance to the European Union (EU) EMC directive, Low Voltage
directive, and RoHS directive.
For CE Mark-Related Questions:
Intel Corporation
Attn: Corporate Quality
2200 Mission College Blvd.
Santa Clara, CA 95054-1549
USA
Australian Communications Authority (ACA) and New Zealand Radio Spectrum
Management (NZ RSM) C-tick mark. Includes adjacent Intel supplier code number,
N-232.
Japan VCCI (Voluntary Control Council for Interference) mark.
Korea Certification mark. Includes an adjacent MSIP (Ministry of Science, ICT & Future
Planning) certification number:
MSIP-REM-CPU-NUC5i5RYB and MSIP-REM-CPU-NUC5i3RYB
Taiwan BSMI (Bureau of Standards, Metrology and Inspections) mark. Includes
adjacent Intel company number, D33025.
Printed wiring board manufacturer’s recognition mark. Consists of a unique UL
recognized manufacturer’s logo, along with a flammability rating (solder side).
V-0
China RoHS/Environmentally Friendly Use Period Logo: This is an example of the
symbol used on Intel NUC and associated collateral. The color of the mark may vary
depending upon the application. The Environmental Friendly Usage Period (EFUP) for
Intel NUC has been determined to be 10 years.
