Regulatory Compliance and Battery Disposal Information
71
Japan VCCI Statement
Japan VCCI Statement translation: This is a Class B product based on the standard of the
Voluntary Control Council for Interference from Information Technology Equipment (VCCI). If this
is used near a radio or television receiver in a domestic environment, it may cause radio
interference. Install and use the equipment according to the instruction manual.
Korea Class B Statement
Korea Class B Statement translation: This equipment is for home use, and has acquired
electromagnetic conformity registration, so it can be used not only in residential areas, but also
other areas.
