Intel NUC Board NUC5i5RYB and Intel NUC Board NUC5i3RYB Technical Product Specification
iv
Preface
This Technical Product Specification (TPS) specifies the board layout, components, connectors,
power and environmental requirements, and the BIOS for Intel® NUC Board NUC5i5RYB and
Intel® NUC Board NUC5i3RYB.
Intended Audience
The TPS is intended to provide detailed, technical information about Intel® NUC Board
NUC5i5RYB and Intel® NUC Board NUC5i3RYB and its components to the vendors, system
integrators, and other engineers and technicians who need this level of information. It is
specifically not intended for general audiences.
What This Document Contains
Chapter
Description
1
A description of the hardware used on Intel® NUC Board NUC5i5RYB and Intel® NUC Board
NUC5i3RYB
2
A map of the resources of the Intel NUC Board
3
The features supported by the BIOS Setup program
4
A description of the BIOS error messages, beep codes, and POST codes
5
Regulatory compliance and battery disposal information
Typographical Conventions
This section contains information about the conventions used in this specification. Not all of
these symbols and abbreviations appear in all specifications of this type.
Notes, Cautions, and Warnings
NOTE
Notes call attention to important information.
CAUTION
Cautions are included to help you avoid damaging hardware or losing data.
