Intel NUC Board NUC5i5RYB and Intel NUC Board NUC5i3RYB Technical Product Specification
22
1.5.1.3 Mini High Definition Multimedia Interface* (Mini HDMI*)
The Mini High-Definition Multimedia Interface (Mini HDMI) is provided for transmitting
uncompressed digital audio and video signals to television sets, projectors and other video
displays. It can carry high quality multi-channel audio data and all standard and high-definition
consumer electronics video formats. The Mini HDMI display interface connecting the processor
and display devices utilizes transition minimized differential signaling (TMDS) to carry audio visual
information through the same Mini HDMI cable. The processor HDMI interface is designed
according to the High-Definition Multimedia Interface Specification with 3D, Deep Color, and
x.v.Color. The maximum supported resolution is 1920 x 1200 @ 60 Hz, 24bpp or up to 4096 x
2304 @ 24Hz, 24bpp. The Mini HDMI port is compliant with the HDMI 1.4a specification.
1.5.1.4 Mini DisplayPort*
DisplayPort is a digital communication interface that utilizes differential signaling to achieve a high
bandwidth bus interface designed to support connections between PCs and monitors, projectors,
and TV displays. DisplayPort is suitable for display connections between consumer electronics
devices such as high definition optical disc players, set top boxes, and TV displays. The maximum
supported resolution is 3840 x 2160 @ 60 Hz, 30bpp. The Mini DisplayPort is compliant with the
DisplayPort 1.2 specification.
DisplayPort output supports Multi-Stream Transport (MST) which allows for multiple independent
video streams (daisy-chain connection with multiple monitors) over a single DisplayPort. This will
require the use of displays that support DisplayPort 1.2 and allow for this feature.
For information about Refer to
DisplayPort technology http://www.displayport.org
1.5.1.4.1 DisplayPort 1.2 Multi-Stream Transport Daisy-Chaining
Table 5 lists the maximum resolutions available when using DisplayPort 1.2 Multi-Stream
Transport.
Table 5. DisplayPort Multi-Streaming Resolutions
DisplayPort Usage Models Monitor 1 Monitor 2 Monitor 3
3 Monitors 1920 x 1200 @ 60 Hz 1920 x 1080 @ 60 Hz 1920 x 1080 @ 60 Hz
2 Monitors 2560 x 1600 @ 60 Hz 2560 x 1600 @ 60 Hz
3 Monitors
(with DisplayPort 1.2 hub)
1920 x 1080 @ 60 Hz 1920 x 1080 @ 60 Hz 1920 x 1080 @ 60 Hz
1.5.1.5 Multiple DisplayPort and HDMI Configurations
Multiple DisplayPort and HDMI configurations feature the following:
• Two independent displays
• Single HDMI 1.4a with 1080P support
• Single DisplayPort 1.2 with 4K support
• Collage Display
