1 Product Description
1.1 Overview
1.1.1 Feature Summary
Table 1 summarizes the major features of Intel® NUC Board NUC5i5RYB and Intel® NUC Board
NUC5i3RYB.
Table 1. Feature Summary
Form Factor
4.0 inches by 4.0 inches (101.60 millimeters by 101.60 millimeters)
Processor
•
Intel® NUC Board NUC5i5RYB has a soldered-down 5
th
generation Intel® Core™ i5-5250U
dual-core processor with up to a maximum 25 W TDP (if thermal margin available)
― Integrated graphics HD6000
― Integrated memory controller
― Integrated PCH
• Intel® NUC Board NUC5i3RYB has a soldered-down 5
th
generation Intel® Core™ i3-5010U
dual-core processor with up to a maximum 25 W TDP (if thermal margin available)
― Integrated graphics HD5500
― Integrated memory controller
― Integrated PCH
Memory
• Two 204-pin DDR3L SDRAM Small Outline Dual Inline Memory Module (SO-DIMM)
sockets
• Support for DDR3L 1600/1333 MHz SO-DIMMs
• Support for 2 Gb and 4 Gb memory technology
• Support for up to 16 GB of system memory with two SO-DIMMs using 4 Gb memory
technology
• Support for non-ECC memory
• Support for 1.35 V low voltage JEDEC memory only
Graphics
•
Integrated graphics support for processors with Intel® Graphics Technology:
― One Mini High Definition Multimedia Interface* (Mini HDMI*) back panel connector
― One Mini DisplayPort* back panel connector
Audio
•
Intel® High Definition (Intel
®
HD) Audio via the Mini HDMI v1.4a and Mini DisplayPort 1.2
interfaces through the processor
• Realtek HD Audio via a stereo microphone/headphone 3.5 mm jack on the front panel
Storage
• SATA ports:
― One SATA 6.0 Gb/s port (blue) for 2.5“ storage device
• One SATA 6.0 Gb/s port is reserved for an M.2 storage module supporting M.2 2242,
M.2 2260, and M.2 2280 (key type M) modules
Note: Intel NUC Board NUC5i5RYB and Intel NUC Board NUC5i3RYB support key type M
(PCI Express x1/x2/x4 and SATA)
Peripheral Interfaces
•
USB 3.0 ports:
― Two ports are implemented with external front panel connectors (blue and orange)
― Two ports are implemented with external back panel connectors (blue)
• USB 2.0 ports:
― Two ports via one dual-port internal 1x8 1.25 mm pitch header (white)
― One port is reserved for an M.2 1216 module
