Datasheet

Intel Confidential 5
BBS2600CP2J
921042
735858244800
5032037039376
10
Intel® Server Board S2600CP2 OEM 10-pack with Dual NIC
 Supports Dual Intel® Xeon E5-2600 processors 135W max
 Intel® C602J chipset
 16 DDR3/DDR3L DIMM slots
 6 PCIe slots
 2 SATA 6G AHCI ports and 4 SATA 3G AHCI ports (no SCU
SATA/SAS ports are supported in this SKU)
 Intel® Dual Gigabit Ethernet with Intel® Virtualization
Technology
 Integrated Baseboard Management Controller with IPMI 2.0
 Option for advanced management functions with KVM
(AXXRMM4LITE) and dedicated NIC for remote
management (AXXRMM4).
 Support for Intel® SAS and RAID modules in PCIe form
factor. Module sold separately.
*Does not include IO shield. IO shield (AXX2IOS) sold
separately.
Note: Only available in a 10-pack and only available upon request,
build to order.
DBS2600CP2
916040
735858238823
5032037033602
5
Intel® Server Board S2600CP2 Retail Single pack with Dual NIC
 Supports Dual Intel® Xeon E5-2600 processors 135W max
 Intel® C600 series chipset
 16 DDR3/DDR3L DIMM slots
 6 PCIe slots
 8 SCU SATA/SAS ports (4 ports functional w/ no storage
keys and 4 ports require storage keys)
 2 SATA 6G AHCI ports and 4 SATA 3G AHCI ports
 Intel® Dual Gigabit Ethernet with Intel® Virtualization
Technology
 Integrated Baseboard Management Controller with IPMI 2.0
 Option for advanced management functions with KVM
(AXXRMM4LITE) and dedicated NIC for Remote
Management (AXXRMM4).
 Support for Intel® SAS and RAID modules in PCIe form
factor. Module sold separately.
 IO shield included.
And
DBS2600CP2IOC
920971
735858244817
5032037039383
5
Intel® Server Board S2600CP2 Retail Single pack with Dual NIC and
6 Gb/s SAS
 Supports Dual Intel® Xeon E5-2600 processors 135W max
 Intel® C600 series chipset
 16 DDR3/DDR3L DIMM slots
 6 PCIe slots
 8 SCU SATA/SAS ports (4 ports functional w/ no storage
keys and 4 ports require storage keys)
 2 SATA 6G AHCI ports and 4 SATA 3G AHCI ports
 Intel® Dual Gigabit Ethernet with Intel® Virtualization
Technology
 Integrated Baseboard Management Controller with IPMI 2.0
 Option for advanced management functions with KVM
(AXXRMM4LITE) and dedicated NIC for Remote
Management (AXXRMM4).
 Intel® 6Gb/s SAS module in PCIe form factor included.
 Includes IO shield
