1.5 insErt BAttErY/sd cArd/siM cArd
1. Turn phone over and locate slot on bottom.
2. Pull up on slot to remove back cover.
3. Insert card(s) according to diagram.
4. Insert battery with arrow pointing to top of phone.
TIP: For additional media storage, insert an SD card.
TIP: Data can be enabled on only one SIM card at a time. The slot labelled
SIM 1 is the default position for data usage.
1.4 chArGE thE BAttErY
Before using your phone for the first time, charge the phone for four hours.
To charge the battery:
1. Attach one end of the USB cord to the phone’s micro-USB port and the
other end to the plug.
2. Plug the phone into the wall.
1.4.1 BAttErY tiPs
For the best battery life, let your battery drain down to 20% or less (indicated
by an orange battery icon in the status bar) before recharging, and do not
leave your phone plugged in after it is fully charged.
To make your charge last as long as possible:
• Change the screen timeout rate and display brightness
(see Display Settings).
• Disable Wi-Fi when not in use (see Wireless & Networks Settings).
NOTE: For optimal charging, please use the USB cable and charger provided
with the phone.
Connect this
end to phone’s
USB port.
Plug into wall.
Connect this
end to plug.
