Getting Started Guide
welcome Congratulations on your new phone purchase. This guide will help you to quickly come up to speed on the important features of your phone. Keep in mind your phone has: • Fast Processor: Featuring the Intel® Atom™ processor 1.2GHz that enables fast web browsing, super-responsive apps, and effortless multi-tasking, so that enjoying the things you love to do has never been easier.
your phone – front view Earpiece Power Button Volume Back Menu Home Recent Page: 3
your phone – back view 5.0MP Rear-Facing Camera USB/Power Port 3.
insert battery, SIM cards & SD card Turn phone over and locate slot on bottom. Pull up on slot to remove back cover. Insert card(s) according to diagram. Insert battery with arrow pointing to top of phone. TIP: Data can be enabled on only one SIM card at a time. The slot labelled SIM 1 is the default position for data usage. TIP: For additional media storage, insert an SD card.
charge the battery Plug into wall. Connect this end to phone’s USB port. Connect this end to plug. NOTE: For optimal charging, please use the USB cable and charger provided with the phone.
turn the phone on and off Hold down the power button to turn the phone on. Hold down the power button, then touch Power off to turn the phone off. sleep / lock / wake When the power is on, and you want to put the phone in sleep mode, press the power button. When the phone is in sleep mode, and you want to wake the phone, press the power button to bring up the unlock screen. unlock phone / camera Unlock your phone by dragging the circle lock to the right.
home screen & apps Swipe left or right to see more panels. Touch and hold to change the wallpaper. Touch an app to open it. Touch to browse the web. Touch to make a call. Touch to view contacts. Touch to view all apps. Touch to send a text message. TIP: To move an icon, touch and hold it, then drag the icon to a new location.
status & notifications The Status bar shows your phone’s status and notifications. The Notification panel is your centre for new events—like new email, voicemail, updates, and more. notification status icons Drag down to display notifications. Touch to launch System settings. Touch to clear notifications. NOTE: Select services are displayed across the top of the Notification panel (Wi-Fi, Bluetooth, GPS, Account sync, and Display Brightness). Touch an icon to turn that service ON or OFF.
G82393-001
calling & texting Incoming calls Slide circle here to reject call. Slide circle here to answer call. Place a call 1. From the Home screen, touch . 2. Dial a phone number using the dial pad. 3. Touch to place your call. Set a ringtone 1. From the Home screen, press , then touch System Sound Phone ringtone. settings 2. Touch a ringtone to hear it. Touch OK to select it. Send a text 1. 2. 3. 4. 5. From the Home screen, touch . Touch . Enter a recipient’s name.
using dual SIM cards Set 2G or 3G network 1. From the Home screen, press , then touch System More... (under Wireless & Networks) settings Dual SIM network settings. Mobile networks 2. Choose a tab at the top of the page (SIM 1 or SIM 2), then touch Use only 2G networks. Change data SIM settings: 1. From the Home screen, touch . 2. Touch to launch the SimConfig app. 3. At the bottom of the screen, 1 (by default) is blue and displays APPS. Touch 2 to use SIM 2 for data. Place a call 1.
wireless connections Connect to Wi-Fi 1. From the Home screen, press System settings. 2. If Wi-Fi is OFF, touch OFF to toggle it on. 3. Touch Wi-Fi. The available networks display. 4. Touch a network, then touch Connect. Pair Phone with Bluetooth Device 1. From the Home screen, press System settings. 2. If Bluetooth is OFF, touch OFF to toggle it on. 3. Touch Bluetooth. The available Bluetooth wireless technology-enabled products display. 4. Select the product you wish to pair. 5.
camera & video Take a picture 1. Touch in your apps. 2. Frame your subject in the camera. 3. Touch the Shutter button to take your picture and save the image to the Gallery. For Burst mode, touch MODE, and then touch . Touch the Shutter button to take a series of pictures and save the images to the Gallery. Shoot a video 1. From the Camera app, touch the Mode button, and then select the camcorder. 2. Touch the Shutter button to begin recording.
safety, regulatory & legal SAFETY AND OPERATIONAL GUIDELINES IMPORTANT: Please review and adhere to these simple guidelines. Failure to do so may be dangerous or illegal. All statements, information and recommendations contained herein do not constitute a warranty of any kind, either expressed or implied. The information contained herein is subject to change without notice. Please read the complete user guide for further information.
• Permanent hearing loss may occur if you use earphones or headphones at high volume. You can adapt over time to a higher volume, which may sound normal but can be damaging to your hearing. Set your volume to a safe level. If you experience discomfort or buzzing in your ears, reduce the volume or discontinue use of your earphones or headphones. • Ring tones, info tones and hands-free talking are reproduced through the loudspeaker.
• This phone includes a radio transmitter and receiver to transmit and receive, respectively, electromagnetic energy operating at various radio frequencies (RF energy). The device is designed to operate within local regulatory requirements concerning the exposure of this RF energy to human beings. Nonetheless, however you use your phone, you should keep the phone 15mm away from your body to limit your exposure to RF energy.
“To prevent possible hearing damage, do not listen at high volume levels for long periods.” FCC Statements Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. *Tests for SAR are conducted using standard operating positions accepted by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value.
Notice The information contained herein is subject to change without notice. All statements, information and recommendations contained herein do not constitute a warranty of any kind, either expressed or implied. Please review this product guide thoroughly, with particular attention paid to any safety sections, to make sure that you use your phone safely. Copyright © 2011-2012 Intel Corporation. All rights reserved. This publication is protected by copyright.
