User's Guide

Features and specifications
Dimensions
• Width: 310 mm (12.2 inches)
• Depth: 214 mm (8.42 inches)
• Thickness: 17 mm (0.67 inches)
ac power adapter
• Input: 100 V ac–240 V ac, 50 Hz–60 Hz
• Output: 15 V dc, 3 A
• Power: 45 W
Battery pack
• Capacity: 52.5 Wh
• Number of cells: 4
Memory
• Type: On-board double data rate 4
• Number of slots: 0
Storage device
• Type:
– Embedded multi media card (eMMC)
– Solid-state drive (SSD)
• Bus:
– eMMC 5.1
– PCI Express
Screen
• Size: 337.82 mm (13.3 inches)
• Display resolution: 1920 × 1080 pixels
Connectors and slots
• Combo audio jack
• microSD card slot
• USB Type-A connector
• USB-C connector × 2 (one connector support power connector function)
Security features
• Mini security-lock slot
Wireless features
• Bluetooth
• Wireless LAN
Note: The battery capacity is the typical or average capacity as measured in a specific test environment.
Capacities measured in other environments may differ but are no lower than the rated capacity (see product
label).
Statement on USB transfer rate
Depending on many factors such as the processing capability of the host and peripheral devices, file
attributes, and other factors related to system configuration and operating environments, the actual transfer
rate using the various USB connectors on this device will vary and will be slower than the data rate listed
below for each corresponding device.
