B
i
t
7
B
i
t
6
B
i
t
5
B
i
t
4
B
i
t
3
B
i
t
2
B
i
t
1
B
i
t
0
Hex V
CC
1 0 0 0 0 1 1 0 86h 1.8300
1 0 0 0 0 1 1 1 87h 1.8400
1 0 0 0 1 0 0 0 88h 1.8500
1 0 0 0 1 0 0 1 89h 1.8600
1 0 0 0 1 0 1 0 8Ah 1.8700
1 0 0 0 1 0 1 1 8Bh 1.8800
1 0 0 0 1 1 0 0 8Ch 1.8900
1 0 0 0 1 1 0 1 8Dh 1.9000
1 0 0 0 1 1 1 0 8Eh 1.9100
1 0 0 0 1 1 1 1 8Fh 1.9200
1 0 0 1 0 0 0 0 90h 1.9300
1 0 0 1 0 0 0 1 91h 1.9400
1 0 0 1 0 0 1 0 92h 1.9500
1 0 0 1 0 0 1 1 93h 1.9600
1 0 0 1 0 1 0 0 94h 1.9700
1 0 0 1 0 1 0 1 95h 1.9800
1 0 0 1 0 1 1 0 96h 1.9900
1 0 0 1 0 1 1 1 97h 2.0000
1 0 0 1 1 0 0 0 98h 2.0100
1 0 0 1 1 0 0 1 99h 2.0200
1 0 0 1 1 0 1 0 9Ah 2.0300
1 0 0 1 1 0 1 1 9Bh 2.0400
1 0 0 1 1 1 0 0 9Ch 2.0500
1 0 0 1 1 1 0 1 9Dh 2.0600
1 0 0 1 1 1 1 0 9Eh 2.0700
1 0 0 1 1 1 1 1 9Fh 2.0800
1 0 1 0 0 0 0 0 A0h 2.0900
1 0 1 0 0 0 0 1 A1h 2.1000
1 0 1 0 0 0 1 0 A2h 2.1100
1 0 1 0 0 0 1 1 A3h 2.1200
1 0 1 0 0 1 0 0 A4h 2.1300
1 0 1 0 0 1 0 1 A5h 2.1400
1 0 1 0 0 1 1 0 A6h 2.1500
1 0 1 0 0 1 1 1 A7h 2.1600
continued...
B
i
t
7
B
i
t
6
B
i
t
5
B
i
t
4
B
i
t
3
B
i
t
2
B
i
t
1
B
i
t
0
Hex V
CC
1 0 1 0 1 0 0 0 A8h 2.1700
1 0 1 0 1 0 0 1 A9h 2.1800
1 0 1 0 1 0 1 0 AAh 2.1900
1 0 1 0 1 0 1 1 ABh 2.2000
1 0 1 0 1 1 0 0 ACh 2.2100
1 0 1 0 1 1 0 1 ADh 2.2200
1 0 1 0 1 1 1 0 AEh 2.2300
1 0 1 0 1 1 1 1 AFh 2.2400
1 0 1 1 0 0 0 0 B0h 2.2500
1 0 1 1 0 0 0 1 B1h 2.2600
1 0 1 1 0 0 1 0 B2h 2.2700
1 0 1 1 0 0 1 1 B3h 2.2800
1 0 1 1 0 1 0 0 B4h 2.2900
1 0 1 1 0 1 0 1 B5h 2.3000
1 0 1 1 0 1 1 0 B6h 2.3100
1 0 1 1 0 1 1 1 B7h 2.3200
1 0 1 1 1 0 0 0 B8h 2.3300
1 0 1 1 1 0 0 1 B9h 2.3400
1 0 1 1 1 0 1 0 BAh 2.3500
1 0 1 1 1 0 1 1 BBh 2.3600
1 0 1 1 1 1 0 0 BCh 2.3700
1 0 1 1 1 1 0 1 BDh 2.3800
1 0 1 1 1 1 1 0 BEh 2.3900
1 0 1 1 1 1 1 1 BFh 2.4000
1 1 0 0 0 0 0 0 C0h 2.4100
1 1 0 0 0 0 0 1 C1h 2.4200
1 1 0 0 0 0 1 0 C2h 2.4300
1 1 0 0 0 0 1 1 C3h 2.4400
1 1 0 0 0 1 0 0 C4h 2.4500
1 1 0 0 0 1 0 1 C5h 2.4600
1 1 0 0 0 1 1 0 C6h 2.4700
1 1 0 0 0 1 1 1 C7h 2.4800
1 1 0 0 1 0 0 0 C8h 2.4900
1 1 0 0 1 0 0 1 C9h 2.5000
continued...
Electrical Specifications—Processor
Desktop 4th Generation Intel
®
Core
™
Processor Family, Desktop Intel
®
Pentium
®
Processor Family, and Desktop Intel
®
Celeron
®
Processor Family
December 2013 Datasheet – Volume 1 of 2
Order No.: 328897-004 93
