32-Bit High-Performance Superscalar Processor Data Sheet

80960HA/HD/HT
Datasheet 99
“ONCEBAR : 6,”&
“PCHKBAR : 189,”&
“READYBAR : 68,”&
“RESETBAR : 174,”&
“STEST : 208,”&
“SUPBAR : 97,”&
“TCK : 194,”&
“TDI : 191,”&
“TDO : 188,”&
“TMS : 192,”&
“TRST : 193,”&
“WAITBAR : 90,”&
“WRBAR : 88,”&
“XINTBAR : (169, 168, 167, 166, 163, 162, 161, 160),”&
“FIVEVREF : 197,”&
“VCCPLL : 177,”&
“VCC1 : (1, 4, 9, 11, 17, 19, 25, 31, 33, 38, 44, 46,”&
“ 49, 59, 60, 66, 71, 74, 76, 81, 87, 92, 95, 101),”&
“VCC2 : (102, 109, 115, 117, 123, 128, 131, 137, 143, 149,”&
“ 153, 154, 158, 165, 171, 173, 176, 179, 185, 187,”&
“ 196, 199, 201, 204),”&
“VSS1 : (2, 3, 7, 8, 16, 18, 24, 30, 32, 43, 47, 48,”&
“ 53, 58, 65, 70, 73, 75, 80, 86, 93, 94, 98, 103),”&
“VSS2 : (108, 114, 116, 122, 129, 130, 136, 142, 148, 152,”&
“ 155, 156, 157, 164, 170, 172, 178, 184, 186, 190,”&
“ 195, 198, 200, 205)”;
attribute Tap_Scan_In of TDI : signal is true;
attribute Tap_Scan_Mode of TMS : signal is true;
attribute Tap_Scan_Out of TDO : signal is true;
attribute Tap_Scan_Reset of TRST : signal is true;
attribute Tap_Scan_Clock of TCK : signal is (66.0e6, BOTH);
attribute Instruction_Length of Ha_Processor: entity is 4;
attribute Instruction_Opcode of Ha_Processor: entity is
Example 2. Boundary-Scan Description Language (BSDL) for PQ2
Package Example (Sheet 4 of 8)
