“D : (E03, C02, D02, C01, E02, D01, F02, E01, F01,”&
“ G01, H02, H01, J01, K01, L02, L01, M01, N01,”&
“ N02, P01, P02, Q01, P03, Q02, R01, S01, Q03,”&
“ R02, Q04, S02, Q05, R03),”&
“DENBAR : S09,”&
“DP : (A03, B03, A04, B04),”&
“DTRBAR : S11,”&
“DCBAR : S13,”&
“FAILBAR : A02,”&
“HOLD : R05,”&
“HOLDA : S04,”&
“LOCKBAR : S14,”&
“NMIBAR : D15,”&
“ONCEBAR : C03,”&
“PCHKBAR : B08,”&
“READYBAR : S03,”&
“RESETBAR : A16,”&
“STEST : B02,”&
“SUPBAR : Q12,”&
“TCK : B05,”&
“TDI : A07,”&
“TDO : A08,”&
“TMS : B06,”&
“TRST : A06,”&
“WAITBAR : S12,”&
“WRBAR : S10,”&
“ XINTBAR : (B15, A15, A17, B16, C15, B17, C16, C17),”&
“FIVEVREF : C05,”&
“VOLTDET : A05,”&
“VCCPLL : B10,”&
“ VCC1 : (M02, K02, J02, G02, N03, F03, C06, B07, B09, B11,”&
“ B12, C14, E15, F16, H16, J16, K16, M16, N15, Q06,”&
“ R07, R08, R10, R11),”&
“ VSS1 : (G03, H03, J03, K03, L03, M03, C07, C08, C09, C10,”&
“ C11, C12, Q07, Q08, Q09, Q10, Q11, F15, G15, H15,”&
“ J15, K15, L15, M15, A01, C04),”&
“NC : (A09, A10, B13, B14, D03)”;
Example 1. Boundary-Scan Description Language (BSDL) for PGA
Package Example (Sheet 4 of 8)
