32-Bit High-Performance Superscalar Processor Data Sheet

80960HA/HD/HT
Datasheet 87
XINT7BAR Input
Appears as XINTBAR(7:0) in
BSDL file.
XINT6BAR Input
XINT5BAR Input
XINT4BAR Input
XINT3BAR Input
XINT2BAR Input
XINT1BAR Input
XINT0BAR Input
RESETBAR Input
CLKIN Input
CT3 Output Appears as CT(3:0) in BSDL file.
CT2 Output
CT1 Output
CT0 Output
PCHK Output
Appears as PCHKBAR in BSDL
file.
PCHK enable Control
Table 26. 80960Hx Boundary Scan Chain (Sheet 4 of 4)
# Boundary Scan Cell Cell Type Comment
NOTES:
1. Cell#1 connects to TDO and cell #112 connects to TDI.
2. All outputs are tri-state.
3. In output and bidirectional signals, a logical 1 on the enable signal enables the output. A logical 0
tri-states the output.
