32-Bit High-Performance Superscalar Processor Data Sheet

80960HA/HD/HT
Datasheet 35
Table 16. Fields of 80960Hx Device ID
Field Value Definition
Version See Table 18. Indicates major stepping changes.
V
CC
1 = 3.3 V device Indicates that a device is 3.3 V.
Product Type
00 0100
(Indicates i960 CPU)
Designates type of product.
Generation Type 0010 = H-series Indicates the generation (or series) the product belongs to.
Model See
Table 17.
Indicates member within a series and specific model
information.
Manufacturer ID
000 0000 1001
(Indicates Intel)
Manufacturer ID assigned by IEEE.
Table 17. 80960Hx Device ID Model Types
Device Version V
CC
Product Gen. Model Manufacturer ID 1
80960HA
See
Table 18.
1 000100 0010 00000 00000001001 1
80960HD 1 000100 0010 00001 00000001001 1
80960HT 1 000100 0010 00010 00000001001 1
Table 18. Device ID Version Numbers for Different Steppings
Stepping Version
A0 0000
A1 0001
A2 0001
B0, B2 0010
NOTE: This data sheet applies to the B2 stepping.
