“76 (BC_1, A(19), output3, X, 80, 1, Z),” &
“77 (BC_1, A(18), output3, X, 80, 1, Z),” &
“78 (BC_1, A(17), output3, X, 80, 1, Z),” &
“79 (BC_1, A(16), output3, X, 80, 1, Z),” &
“80 (BC_1, *, control, 1),” &
“81 (BC_1, A(15), output3, X, 80, 1, Z),” &
“82 (BC_1, A(14), output3, X, 80, 1, Z),” &
“83 (BC_1, A(13), output3, X, 80, 1, Z),” &
“84 (BC_1, A(12), output3, X, 80, 1, Z),” &
“85 (BC_1, A(11), output3, X, 80, 1, Z),” &
“86 (BC_1, A(10), output3, X, 80, 1, Z),” &
“87 (BC_1, A(9), output3, X, 80, 1, Z),” &
“88 (BC_1, A(8), output3, X, 80, 1, Z),” &
“89 (BC_1, A(7), output3, X, 80, 1, Z),” &
“90 (BC_1, A(6), output3, X, 80, 1, Z),” &
“91 (BC_1, A(5), output3, X, 80, 1, Z),” &
“92 (BC_1, A(4), output3, X, 80, 1, Z),” &
“93 (BC_1, A(3), output3, X, 80, 1, Z),” &
“94 (BC_1, A(2), output3, X, 80, 1, Z),” &
“95 (BC_4, NMIBAR, input, X),” &
“96 (BC_4, XINTBAR(7), input, X),” &
“97 (BC_4, XINTBAR(6), input, X),” &
“98 (BC_4, XINTBAR(5), input, X),” &
“99 (BC_4, XINTBAR(4), input, X),” &
“100(BC_4, XINTBAR(3), input, X),” &
“101(BC_4, XINTBAR(2), input, X),” &
“102(BC_4, XINTBAR(1), input, X),” &
“103(BC_4, XINTBAR(0), input, X),” &
“104(BC_4, RESETBAR, input, X),” &
“105(BC_4, CLKIN, input, X),” &
“106(BC_1, CT(3), output3, X, 80, 1, Z),” &
“107(BC_1, CT(2), output3, X, 80, 1, Z),” &
“108(BC_1, CT(1), output3, X, 80, 1, Z),” &
“109(BC_1, CT(0), output3, X, 80, 1, Z),” &
“110(BC_1, PCHKBAR, output3, X, 111,1, Z),” &
“111(BC_1, *, control, 1)”;
end Ha_Processor;
Example 2. Boundary-Scan Description Language (BSDL) for PQ2
Package Example (Sheet 8 of 8)
