32-Bit High-Performance Superscalar Processor Data Sheet

80960HA/HD/HT
100 Datasheet
“BYPASS (1111),” &
“EXTEST (0000),” &
“SAMPLE (0001),” &
“IDCODE (0010),” &
“RUBIST (0111),” &
“CLAMP (0100),” &
“HIGHZ (1000),” &
“Reserved (1011, 1100)”;
attribute Instruction_Capture of Ha_Processor: entity is “0001”;
attribute Instruction_Private of Ha_Processor: entity is “Reserved” ;
attribute Idcode_Register of Ha_Processor: entity is
“0001” & version,
“1000100001000000” & part number
“00000001001”& manufacturers identity
“1”; required by the standard
attribute Register_Access of Ha_Processor: entity is
“Runbist[32] (RUBIST),” &
“Bypass (CLAMP, HIGHZ)”;
*******************************************************************************
{ The first cell, cell 0, is closest to TDO }
{ BC_1:Control, Output3 CBSC_1:Bidir BC_4: Input, Clock }
*******************************************************************************
attribute Boundary_Cells of Ha_Processor: entity is “BC_4, BC_1, CBSC_1”;
attribute Boundary_Length of Ha_Processor: entity is 112;
attribute Boundary_Register of Ha_Processor: entity is
“0 (CBSC_1, DP(3), bidir, X, 17, 1, Z),” &
“1 (CBSC_1, DP(2), bidir, X, 17, 1, Z),” &
“2 (CBSC_1, DP(0), bidir, X, 17, 1, Z),” &
“3 (CBSC_1, DP(1), bidir, X, 17, 1, Z),” &
“4 (BC_4, STEST, input, X),” &
“5 (BC_1, FAILBAR, output3, X, 6, 1, Z),” &
Example 2. Boundary-Scan Description Language (BSDL) for PQ2
Package Example (Sheet 5 of 8)
