32-Bit High-Performance Superscalar Processor Data Sheet

80960HA/HD/HT
86 Datasheet
LOCKBAR Output
BREQ Output
A31 Output
A30 Output
A29 Output
A28 Output
A27 Output
A26 Output
A25 Output
A24 Output
A23 Output
A22 Output
A21 Output
A20 Output
A19 Output
A18 Output
A17 Output
A16 Output
Enable for A(31:0) and CT(3:0) Control
A15 Output
A14 Output
A13 Output
A12 Output
A11 Output
A10 Output
A9 Output
A8 Output
A7 Output
A6 Output
A5 Output
A4 Output
A3 Output
A2 Output
NMIBAR Input
Table 26. 80960Hx Boundary Scan Chain (Sheet 3 of 4)
# Boundary Scan Cell Cell Type Comment
NOTES:
1. Cell#1 connects to TDO and cell #112 connects to TDI.
2. All outputs are tri-state.
3. In output and bidirectional signals, a logical 1 on the enable signal enables the output. A logical 0
tri-states the output.
