User guide

If a baery is le in the charger for a signiﬁcant period of time aer it is fully charged, it will automati-

cally stop charging and display a ﬂashing red light.

Indications: The LED Loupes Light Source is intended for use ONLY in conjunction with magniﬁcation loupes and

should not be used without them. The light source is used to

illuminate the magniﬁed ﬁeld only.

Rx Only: Caution: Federal (US) law restricts this device to sale by or on the order of a physician.

Contents:

1. LED lamp head and cable with loupes mount

2. Power pack with one lithium-ion rechargeable baery

3. Baery charger and AC wall adapter

1. Charge baery

Plug the power adapter into a power outlet and connect to charger unit.

a. A single red light will indicate power to the unit. If the red light does not appear, remove the baery

from the charger, unplug the power adapter from the charger unit and wait 5 minutes before

reconnecting. If the red light still does not appear, call Miltex Customer Support.

b. Slide the baery into the Charger Unit. Be sure the baery terminals are securely connected to

the Charger terminals.

c. The following lights on the Charger Unit indicate the baery charge status:

MILTEX

PORTABLE LED LOUPES LIGHT SOURCE

DIRECTIONS FOR USE
