Tools & Technologies Innovative Parts Cart - B Series™ Manual

Parts Cart Nesting Instructions

Start with bottom shelf, using

dedicated nesting hole.

Repeat process with middle

shelf

Repeat process with top shelf

and store support arms as

shown.

Two carts nested.

Note that even when optional

accessories are installed, the nesting is

not affected. Optional Panel Train shown.

Using support arms on the rear of the

cart, large panels and cartons can be

secured with supplied bungee cords.

Secure boxes on shelves with

supplied bungee cords.

1 2 3

PAGE 1
Parts Cart Nesting Instructions 1 Start with bottom shelf, using dedicated nesting hole. 2 Repeat process with middle shelf 3 Repeat process with top shelf and store support arms as shown. Secure boxes on shelves with supplied bungee cords. Two carts nested. Note that even when optional accessories are installed, the nesting is not affected. Optional Panel Train shown. Using support arms on the rear of the cart, large panels and cartons can be secured with supplied bungee cords.
PAGE 2
Parts Cart Accessories Be Parts Smart – Customize Your Cart Innovative Parts Pan™ P/N: SSPC-PP Innovative RO Holder™ P/N: SSPC-RO Innovative Hanger Bracket™ P/N: SSPC-HBK Trim Panel Bag Headlight Bag 49x38 24x38 Innovative Hardware Tray™ P/N: SSPC-HT Innovative Panel Train™ P/N: SSPC-PT Innovative Deep Basket™ P/N: SSPC-DB www.innovativetools.
