If the current supervisory PC uses a proxy server to access the Internet, it is required to cancel
the proxy service. The operating steps are shown below: 1) In the browser window, select
"tools>>Internet options"; 2) select "connection" page and click the button of LAN Settings to
enter "LAN Settings" window interface. Please confirm if the option "Use a Proxy Server for LAN"
is checked; if it is checked, please cancel and click the button <OK>.
IV. Log in/Exit Web Settings Page
Open IE or other browser and enter IP address of IR611-S, such as http://192.168.2.1 in address
bar (default setting of IR611-S). Upon connection, log in from the login interface as a system
admin, i.e. enter username and password at the login interface (user name /password default:
adm/123456).
For security, you are suggested to modify the default login password after the first login
and safe keep the password information.
III. Web Configuration
Prior to use, the device shall be effectively configured. This chapter will introduce how to
configure your router via Web.
3. 1 System
The system configuration process involves ten steps, including basic setup, system time, serial
port, admin access, system Log, configuration management, task schedule, update, reboot and
logout. Here, system and network state and system time of synchronizing device and PC can be
checked and router WEB configuration interface language can be set as well as the name of
mainframe of router can be customized.
