2.4 Installation of Protective Grounding
The specific steps are shown in below:
Step 1: Remove the grounding screw.
Step 2: Connect the grounding ring of the cabinet’s grounding wire onto the grounding
screw.
Step 3: Tighten the grounding screw up.
To improve the immunity from interference of whole router, the router must be grounded when
using. According to operating environment, the ground wire should be connected with
grounding stud of router.
2.5 Installation of Power Supply
Upon installation of the antenna, connect the device to 9~26V DC power and see if the Power
LED on the panel of the device is on. If not, please contact technical support of InHand Networks
immediately.
2.6 Login Router
Upon installation of hardware, be sure the Ethernet card has been mounted in the supervisory PC
prior to logging in the page of Web settings of the router.
I. Automatic Acquisition of IP Address (Recommended)
Please set the supervisory computer to "automatic acquisition of IP address" and "automatic
acquisition of DNS server address" (default configuration of computer system) to let the device
automatically assign IP address for supervisory computer.
II. Set a Static IP Address
Set the IP address of supervisory PC (such as 192. 168. 2. 2) and LAN interface of device in same
network segment (initial IP address of LAN interface of device: 192. 168. 2. 1, subnet mask: 255.
255. 255. 0).
III. Cancel the Proxy Server
