Serial port: At least one
Ethernet port: At least one (10M/100M)
IE version: Above 5.0
Resolution ratio: Above 640*480
 1 SIM card:
Ensure the card is enabled with data service and its service is not suspended
because of an overdue charge.
 Power supply:
220V AC: Alternatively used with the product with DC power
9~26V DC: Ripple voltage < 100 mV
 Fixation:
Please place InRouter level and have it installed in an environment with small
vibrational frequency.
The device shall be installed and operated when powered off!
2.2 Installation of SIM/UIM Card
IR6XX-S series apply pop-up card holder. Press the yellow button on the right of the card holder
and the card holder will pop up. Then, install the SIM/UIM card and press the card holder back to
the card slot.
2.3 Installation of Antenna
Slightly rotate the movable part of metal SMA-J interface until it cannot be rotated (at this time,
external thread of antenna cable cannot be seen). Do not forcibly screw the antenna by holding
black rubber lining.
