47103767_ed1 EN-1
EN
Product Safety Information
Intended Use:
This Air Impact Wrench are designed to remove and install threaded fasteners.
For additional information refer to Air Impact Wrench Product Safety Information Manual
Form 04580916.
Manuals can be downloaded from www.ingersollrandproducts.com.
Power Management System
For models that include a power management system, the system allows operator reduction
of maximum output power in the forward direction. The power management system does not
a ect the output power in the reverse direction.
To adjust the power, rotate the Power Regulator to the desired level indicator.
The power level indicators are for reference and DO NOT indicate a speci c power. The power
output can be further reduced in forward or reverse by using the variable throttle.
Product Speci cations
Model Style
Drive
Impacts
per min.
Recommended
Torque Range
Type Size
Forward
ft-lbs (Nm)
Reverse
ft-lbs (Nm)
2145QiMAX Pistol Square 3/4” 1150
200-900 [1100 Max.]
(271-1220 [1491 Max.])
200-1000 [1350 Max.]
(271-1356 [1830 Max.])
2145QiMAX-3 Pistol
Square
3” Extended
3/4” 1150
200-900 [1100 Max.]
(271-1220 [1491 Max.])
200-1000 [1350 Max.]
(271-1356 [1830 Max.])
2145QiMAX-6 Pistol
Square
6” Extended
3/4” 1150
200-900 [1100 Max.]
(271-1220 [1491 Max.])
200-1000 [1350 Max.]
(271-1356 [1830 Max.])
2155QiMAX Pistol Square 1” 1150
200-900 [1100 Max.]
(271-1220 [1491 Max.])
200-1000 [1350 Max.]
(271-1356 [1830 Max.])
2145QiMAX-SP Pistol Square 3/4” 1150
200-900 [1100 Max.]
(271-1220 [1491 Max.])
200-1000 [1350 Max.]
(271-1356 [1830 Max.])
2155QiMAX-SP Pistol Square 1” 1150
200-900 [1100 Max.]
(271-1220 [1491 Max.])
200-1000 [1350 Max.]
(271-1356 [1830 Max.])
Models
Impacting Sound Level dB(A)
(ISO15744)
Free Speed Sound Level dB(A)
(ISO15744)
Vibration (m/s)
(ISO28927)
† Pressure (L
p
) ‡ Power (L
w
) † Pressure (L
p
) ‡ Power (L
w
) Level *K
2145QiMAX 96.3 107.3 91.1 102.1 8.7 2.7
2145QiMAX-3 96.3 107.3 91.1 102.1 8.7 2.7
2145QiMAX-6 96.3 107.3 91.1 102.1 8.7 2.7
2155QiMAX 96.3 107.3 91.1 102.1 8.7 2.7
2145QiMAX-SP
96.3 107.3 91.1 102.1 8.7 2.7
2155QiMAX-SP
96.3 107.3 91.1 102.1 8.7 2.7
† K
pA
= 3dB measurement uncertanity
‡ K
wA
= 3dB measurement uncertanity
* K = Vibration measurement uncertanity
