Specifications58
Specifications
Projector specifications
All specifications are subject to change without notice.
Optical
Resolution
1024 x 768 XGA
Display system
1-CHIP DMD
Lens F/Number
F=2.42 (fixed)
Lamp
200 W lamp
Electrical
Power supply
AC100–240V, 3.2A, 50-60 Hz
(Automatic)
Power consumption
365 W (Max); 5 W (Standby)
Mechanical
Weight
8.8 lbs (4.0 Kg)
Output terminals
RGB output
D-Sub 15-pin (female) x 1
Speaker
(Stereo) 2 watt x 1
12VDC (Max. 1A)
Control
USB serial control
Type mini B
RS-232 serial control
Mini Din 8 pin x 1
Input terminals
Computer input
RGB input
D-Sub 15-pin (female) x 1
DVI-I input
Video signal input
S-VIDEO
Mini DIN 4-pin port x 1
VIDEO
RCA jack x 1
SD/HDTV signal input
Analog - Component RCA jack x 3
(through RGB input)
Digital - DVI (supports HDCP)
Audio signal input
Audio in
PC audio jack
Environmental Requirements
Operating temperature
0°C–40°C at sea level
Operating relative humidity
10%–90% (without condensation)
Operating altitude
0–1499 m at 0°C–35°C
1500–3000 m at 0°C–30°C (with
High Altitude Mode on)—
