Declaration of Conformity FCC Warning Manufacturer: InFocus Corporation, 13190 SW 68th Parkway, Suite 200, Portland, Oregon 97223-8368 USA This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Table of Contents Introduction Positioning the projector Connecting a computer source VGA connection HDMI connection Connecting power Optional computer connections Displaying an image Adjusting the image Connecting a video device Video device connections Composite video connection VGA connection Component video connection S-video connection Shutting down the projector Troubleshooting your setup Using the remote control Using the audio Using the keypad buttons Optimizing computer images Presentation features
Important Operating Considerations for Safety • Refer all service to qualified service personnel. Servicing your own projector can be dangerous to you and will void the warranty. • Refer to this guide for proper startup and shutdown procedures. • Follow all warnings and cautions in this manual and on the projector. • • Place the projector in a horizontal position no greater than 15 degrees off axis. Only use replacement parts specified by InFocus.
Introduction Your new digital projector is simple to connect, easy to use, and straightforward to maintain. It is a versatile projector that is flexible enough for business presentations and home video viewing too. IN2124 has native XGA 1024 x 768 resolution, and IN2126 has native WXGA 1280 x 800 resolution. It is compatible with a wide variety of computers and video devices.
Connector panel The projector provides both computer and video connection options, including: • VGA computer • Composite video • HDMI • S-video • USB mini B connector for firmware upgrades and presentation slide control. • Monitor out, for VGA pass through to an external monitor. • Audio input for video and computer. • Audio output to external speakers. • RS-232 serial control. Command control codes are on our support website at www.infocus.com/support. • LAN for RJ45 LAN control.
Positioning the projector Table 1: IN2124 (XGA) Screen size To determine where to position the projector, consider the size and shape of your screen, the location of your power outlets, and the distance between the projector and the rest of your equipment. Here are some general guidelines: • Position the projector on a flat surface at a right angle to the screen. IN2124 must be at least 45.3” (1.2m) from the projection screen, and IN2126 must be at least 55.4” (1.4m) from the projection screen.
Connecting a computer source connect VGA cable VGA connection Connect one end of the provided computer cable to the Computer in 1/Computer in 2 connector on the projector and the other to the VGA connector on your computer. If you are using a desktop computer, you will need to disconnect the monitor cable from the computer’s video port first. HDMI connection connect HDMI HDMI is a standard, uncompressed, all-digital audio/video interface.
Displaying an image press Power button Press the Power button. The Power LED lights blue, and the fans start to run. When the lamp comes on, the start up screen displays. It can take up to a minute for the image to achieve full brightness. No start up screen? Get help on page 12. Turn on your computer or video device. turn on computer or video device The image should appear on the projection screen. If it doesn’t, press the Source button on the projector’s keypad or remote.
Adjusting the image adjust height If necessary, adjust the height of the projector by rotating the elevator foot to extend the foot. If necessary, rotate the leveling foot located at the rear of the projector. elevator foot Avoid placing your hands near the hot exhaust vent at the front of the projector. adjust distance Position the projector the desired distance from the screen at a 90 degree angle to the screen. See page 6 for a table listing screen sizes and distances. Adjust the zoom or focus.
Connecting a video device Component video connection If your HD video device has component connectors, an optional Component to VGA adapter can be used. Plug the component cable into the video device. Plug the other end of the component cable into the adapter and plug the adapter into the Computer connector. You can connect video devices such as VCRs, DVD players, camcorders, digital cameras, video game consoles, HDTV receivers, and TV tuners to the projector.
Shutting down the projector The Status Indicator Panel on top of the projector indicates the state of the projector and can help you troubleshoot. Auto Off Time POWER The projector also has an Auto Off Time feature that automatically turns the projector off after no active sources are detected and no user interaction with the projector is performed for 30 minutes. By default, this feature is off. You can change the length of time, see page 29.
Problem Solution Result No start up screen Plug power cord into the projector press power button Correct image Startup Screen Only start up screen appears Press the Source button activate laptop’s external port Computer image projected Startup Screen A A Restart laptop A 12
Problem Solution No computer image, just the words “Signal out of range” Result Press the Auto Image button on remote Adjust computer refresh rate (Windows 7: Control Panel > Display > Screen Resolution > Advanced Settings > Adapter tab). Varies per operating system.
Problem Solution Change the computer's "Resolution" setting to match the projector's resolution (Windows 7: Control Panel > Display > Screen Resolution). Varies per operating system. Image fuzzy or cropped A Result Image clear and not cropped A Image not centered on screen A Correct image Move projector, adjust height ( PC ) Force Wide Phase Prevent PC Screen Saver Sync Threshold Tracking Horz Position Vert Position Adjust horizontal or vertical position in Advanced Menu > Image > PC...
Problem Solution Result Image not square Adjust Keystone on keypad Square image Image not sharp Adjust Sharpness in the Basic Menu ( Basic Menu ) Correct image MDL: IN2124 FW: 1.
Problem Image upside down Solution Result Turn off Ceiling Mount in Basic menu A ( Basic Menu ) Correct image MDL: IN2124 FW: 1.24 ◄ Auto ► Execute 50 50 50 Presentation 50 50 Off Aspect Ratio Auto Image Brightness Contrast Keystone Presets Sharpness Volume Ceiling Mount Advanced Menu Image reversed left to right Turn off Rear Project in Advanced Menu > Setup > Image Setup...
Problem Solution Result The video embedded in my PowerPoint presentation does not play on the screen Turn off the internal LCD display on your laptop Embedded video plays correctly A A B A B Lamp won’t turn on, the projector is overheating Make sure vents aren’t blocked, turn off the projector and allow it to cool for one minute Lamp turns on Startup Screen POWER TEMP/LAMP Overheating indicator 17 B
Problem Solution Result “Replace lamp” message appears at startup, lamp won’t turn on Lamp must be replaced (see page 36) Lamp turns on lamp door Startup Screen replace lamp Still need assistance? If you need assistance, visit our website at www.infocus.com/support or call us. See the Warranty/Safety booklet for support contact information. This product is backed by a limited warranty. An extended warranty plan may be purchased from your dealer.
Using the remote control • Ensure the batteries' polarity (+/-) is aligned correctly. • • • • • • • • • • • • Do not mix new and old batteries together, or mix different types of batteries together. • • Replace the batteries as soon as they run out. • Remove batteries from the remote control when storing or not in use for a prolonged period. The remote uses two (2) AAA batteries (not provided).
Using the audio connect audio cable Using the projector’s speakers Connect the audio source to the Audio In connectors to hear audio through the projector speakers. Amplified speakers may also be connected to the projector using the Audio Out connector. To adjust the volume, press the Volume buttons on the remote.
Using the keypad buttons Most buttons are described in detail in other sections, but here is an overview of their functions: Power–turns the projector on and off (page 8). Right arrow/Presets - When the menu is displayed, the right arrow button navi- POWER gates through the menu. When the menu is not displayed, this button cycles SOURCE PRESET through available preset options. Up arrow/Keystone - When the menu is displayed, the up arrow button navigates through the menu.
Optimizing computer images Presentation features After the projector is running and the image is on the screen, you can optimize the image using the onscreen menus. For general information on using the menus, see page 24. Several features are provided to make giving presentations easier. Here is an overview, details are found in the menu section. • • • • • • • Select default image settings using a preset appropriate to your environment. Adjust the Keystone, Contrast, or Brightness (page 25).
Optimizing video images Customizing the projector After your video device is connected properly and the image is on the screen, you can optimize the image using the onscreen menus. For general information on using the menus, see page 24. • Adjust the Keystone, Contrast, Brightness, Color, or Tint (page 25). • Change the Aspect Ratio. Choose the option that best fits your input source (page 25). • Select a Sharpness setting (page 25). • Adjust the Color Temperature. Select a listed warmth value (page 26).
Using the menus 1 To open the menus, press the Menu button on the keypad or remote. (The keypad navigation menus automatically close after 60 seconds if no buttons are pressed.) Use the arrow buttons to move up and down to review the menu options. POWER 2 To enter a submenu, highlight the desired submenu and press > on the keypad PRESET SOURCE or Select on remote. TEMP/LAMP 3 To adjust a menu setting, highlight the desired menu option and press < or > to scroll through the available adjustments.
Basic Menu Basic Menu To adjust the following settings, highlight the setting, use the right and left arrows to adjust the values. Aspect Ratio: Aspect ratio is the ratio of the image width to image height. TV screens are usually 4:3. HDTV and most DVDs are 16:9. Select Auto to have the projector choose the ratio. Choose Native to see the unmodified input with no resizing by the projector. Select 16:9 to watch enhanced widescreen DVDs. Auto Image: resets the projector to the source.
Advanced Menu Advanced Menu ( Advanced Menu ) Image Setup Status/Service Color Space: applies to computer and component video sources. It allows you to select a color space that has been specifically tuned for the input signal. When Auto is selected, the projector automatically determines the standard. To choose a different setting, turn off Auto, then choose RGB for computer sources or choose either REC709 or REC601 for component video sources. MDL: IN2124 FW: 1.24 3D Control... Color... PC... Video...
Overscan: removes noise around the video image. • Mute: turns off all sound. Set Black Level: analyzes the current input image and calculates an offset value which is then added to the analog to digital converter black level value. This ensures optimum black level for each analog source. • Source: brings up a menu of available sources. • Auto Image: resets the projector to the source. • Freeze Screen: pauses the projected image. Setup: • Source Info: the default action.
Lamp... To change the PIN: Programmed Dimming: When enabled, Programmed Dimming enhances contrast ratios in dark scenes and disables Lamp Low Power. Programmed Dimming will impact lamp life and system noise performance. Programmed Dimming works in conjunction with the lamp. If Lamp Low Power is enabled, Programmed Dimming is unavailable. Select “Change PIN...” in the Advanced Menu > Setup > PIN settings menu. Enter the existing PIN. Enter the new PIN.
Timer Mac Address: Abbreviation for Media Access Control Address. Mac Address is a unique ID number assigned to each network adapter. Auto Off Time: automatically turns the projector off after no signals are detected for a preset number of minutes. If an active signal is received before the projector powers down, the image will be displayed. Apply: Save and execute the wired network settings. Restart Network...: Restart network settings.
Controlling the projector through a LAN environment • If the Projector IP Address still does not display, contact your network administrator. ® The projector supports Crestron software. With correct settings for the Network menu, you can manage the projector from a computer using a web browser when the computer and the projector are properly connected to the same local area network.
Controlling the projector remotely through a web browser Once you have the correct IP address for the projector and the projector is on or in standby mode, you can use any computer that is on the same local area network to control the projector. • If you are using Microsoft Internet Explorer, make sure it is version 7.0 or higher. 4 If your projector is connected to a network which supports Simple Mail • The screen shots in this manual are for reference only, and may differ depending on your browser.
To Cc Subject From Email Setting Email Alert SMTP Setting Alert Condition Server User Name Password Fan Error Lamp Error Temperature Error Submit Issue Test Mail About Crestron e-Control® 40 40 40 40 30 21 14 (N/A) (N/A) (N/A) (N/A) (N/A) 1 The Crestron e-Control® page provides a variety of virtual keys to control the projector or adjust the projector’s image. a • / > < $ % + \ ' " are prohibited. a You can press / to reveal more buttons. i a.
2 The Tools page allows you to manage the projector, configure the LAN Please pay attention to the input length and character limitations (including character and punctuation restrictions) listed blow: control settings and remotely access the network operations of this projector. Category Item Crestron Control b c Projector a Network Configuration User Password Admin Password a. This area is only used with a Crestron Control System.
Crestron RoomView 3 The Info page displays the information and status of this projector. From the Crestron RoomView software in the Edit Room page, enter the IP Address (or hostname) as shown on the projector’s on-screen display (OSD) menu, “02” for IPID, and “41794” for the reserved Crestron control port. Press exit to go back to the Crestron remote network operation page.
Maintenance Cleaning the lens 1 Apply a non-abrasive camera lens cleaner to a soft, dry cloth. • Projector must be off and the lens must be at room temperature. • Avoid using an excessive amount of cleaner, and don’t apply the cleaner directly to the lens. Abrasive cleaners, solvents or other harsh chemicals might scratch the lens. 2 Lightly wipe the cleaning cloth over the lens in a circular motion. WARNINGS: • Turn the projector off and unplug power cord before cleaning any part of the projector.
Replacing the projection lamp Hg – Lamp contains mercury. Manage in accordance with local disposal laws. See www.lamprecycle.org. The Lamp Hours timer in the Projector Info menu counts the number of hours the lamp has been in use. Twenty hours before the lamp life expires, the message “Replace lamp” displays on the screen at startup. • NOTE: Be sure to use the InFocus lamp module designed for this projector. You can order new lamps from www.infocus.com (in select areas), your retailer or your dealer.
1 Turn off the projector and unplug the power cord. turn off and unplug projector 2 Wait 60 minutes to allow the projector to cool thoroughly. wait 60 minutes 3 Remove the lamp door, located on top of the projector, by removing the screw on the side of the lamp door, sliding the door forward, and lifting the lamp door off. 4 Loosen the captive screws that attach the lamp housing to the projector.
INDEX Focus 9 Force wide 26 Freeze Screen 27 Numerics G 3D Sync Invert 26 Gamma 26 A H Apply 29 Aspect Ratio 25 Audio In Computer connector 7 Auto Image 25 Auto Off Time 29 Auto Source 28 AV Mute 27 HDTV 25 High Altitude Setting 29 Horizontal Position 26 Horz Shift 27 I Internal Speaker 27 IP Address 29 B K Blank Key 27 Blank Screen 27 Brightness 25 Keypad 27 Keypad buttons 21 Keystone 25 C Cable box 10 Ceiling Mount 27 Closed Captions 27 Color Space 26 Computer In connector 7 Connecting Vide
Prevent PC Screen Saver 26 Programmed Dimming 28 Keypad buttons 21 Menus 24 Positioning 6 Setting up 6 Troubleshooting problems 11 Projector Info 27, 29 Volume button 20 W Warranty 18 web browser 31 Z Zoom 9 R Rear Project 27 Red/Green/Blue Gain 26 Red/Green/Blue Offset 26 Remote control 19 Resetting the projector 29 Restart Network... 29 S Search Screen 28 Service 29 Set Black Level...
