Datasheet

BCP28, BCP48
3 Nov-29-2001
Electrical Characteristics at T
A
= 25°C, unless otherwise specified.
Parameter Symbol UnitValues
min. max.typ.
DC Characteristics
V1--
V
CEsat
Collector-emitter saturation voltage1)
I
C
= 100 mA, I
B
= 0.1 mA
Base-emitter saturation voltage 1)
I
C
= 100 mA, I
B
= 0.1 mA
V
BEsat
- - 1.5
AC Characteristics
-
MHz
f
T
-Transition frequency
I
C
= 50 mA, V
CE
= 5 V, f = 100 MHz
200
-Collector-base capacitance
V
CB
= 10 V, f = 1 MHz
-
C
cb
pF8
1) Pulse test: t ≤ 300µs, D = 2%
