Datasheet
BCP28, BCP48
2 Nov-29-2001
Electrical Characteristics at T
A
= 25°C, unless otherwise specified.
Parameter Symbol Values Unit
min. typ. max.
DC Characteristics
Collector-emitter breakdown voltage
I
C
= 1 mA, I
B
= 0
BCP28
BCP48
V
(BR)CEO
30
60
-
-
-
-
V
Collector-base breakdown voltage
I
C
= 100 µA, I
E
= 0
BCP28
BCP48
V
(BR)CBO
40
80
-
-
-
-
Emitter-base breakdown voltage
I
E
= 10 µA, I
C
= 0
V
(BR)EBO
10 - -
Collector cutoff current
V
CB
= 30 V, I
E
= 0
V
CB
= 60 V, I
E
= 0
BCP28
BCP48
I
CBO
-
-
-
-
100
100
nA
Collector cutoff current
V
CB
= 30 V, I
E
= 0 , T
A
= 150 °C
V
CB
= 60 V, I
E
= 0 , T
A
= 150 °C
BCP28
BCP48
I
CBO
-
-
-
-
10
10
µA
Emitter cutoff current
V
EB
= 4 V, I
C
= 0
I
EBO
- - 100 nA
DC current gain 1)
I
C
= 100 µA, V
CE
= 1 V
BCP28
BCP48
h
FE
4000
2000
-
-
-
-
-
DC current gain 1)
I
C
= 10 mA, V
CE
= 5 V
BCP28
BCP48
h
FE
10000
4000
-
-
-
-
DC current gain 1)
I
C
= 100 mA, V
CE
= 5 V
BCP28
BCP48
h
FE
20000
10000
-
-
-
-
DC current gain 1)
I
C
= 500 mA, V
CE
= 5 V
BCP28
BCP48
h
FE
4000
2000
-
-
-
-
1) Pulse test: t ≤ 300µs, D = 2%
