Front panel Location and function of controls 1. MAIN POWER (I / y ) switches the set on or off. 2. D / E (Programme Up/Down) selects a programme or a menu item. switches the set on from standby. 3. F / G (Volume Down/Up) adjusts the volume. adjusts menu settings. 4. MENU selects a menu. MENU MENU 1 2 3 (Front panel) 4 INPUT SELECT 5. INPUT SELECT selects TV, AV1, AV2, S-VIDEO, COMPONENT RGB-DTV, RGB-PC, RGB-DVI mode. switches the set on from standby. INPUT SELECT 5 6 7 8 6.
AUDIO INPUT DVI INPUT RGB INPUT RS-232C INPUT (CONTROL/SER (CONTROL/SERVICE) VICE) R AUDIO L Y AUDIO INPUT COMPONENT INPUT (480i/480p/720p/1080i) Pb Pr RS-232C INPUT (CONTROL/SERVICE) PORT L AUDIO R AV1 VIDEO L AUDIO R AV2 S-VIDEO ANT..
Installation Power Location This set operates on an AC mains supply, the voltage is as indicated on the label on the back cover. Never apply DC power to the set. In the event of thunderstorms or poweroutages, please pull out the aerial and mains power. Position your set so that no bright light or sunlight falls directly onto the screen. Care should be taken not to expose the set to any unnecessary vibration, moisture, dust or heat.
- Typical wall antenna jack used in apartment buildings, connect the antenna cable as shown below. (Use the correct type of antenna cable for the type of wall antenna jack.) Turn clockwise to tighten. ANT.. IN ANT 75Ω Round Cable AC INPUT Bronze Wire 300Ω Flat Wire Antenna Converter Apartment Buildings Antenna Jack Wall Connection Jack - If you have a 75Ω round cable, insert the bronze wire and then tighten the connection nut.
Connection to External equipment VCR Setup - In Video mode, TV automatically reverts to TV mode if the CH F / G button or number buttons are pressed. L AUDIO R AV1 VIDEO Connection 1 S-VIDEO L AUDIO R AV2 VIDEO ANT. IN Set VCR switch to 3 or 4 and then tune TV to the same channel number. Connection 2 1. Connect the audio/video output jacks on VCR to the corresponding input jacks on the TV.
Connections Connect the audio/video output jacks on the external A/V equipment to the corresponding input jacks on the TV. When connecting the TV to external A/V equipment, match the jack colors (Video = yellow, Audio Left = white, and Audio Right = red). VIDEO L AUDIO R AV1 VIDEO S-VIDEO L AUDIO R AV2 ANT.. IN ANT AC INPUT Viewing Setup 1. Turn on the external A/V equipment. 2. Use the INPUT SELECT button on the remote control to select AV1 or AV2. 3. Operate the corresponding external equipment.
Connection to External equipment DTV Setup - To watch digitally broadcast programs, purchase and connect a digital set-top box. Connections RS-232C INPUT (CONTROL/SER (CONTROL/SERVICE) VICE) R AUDIO L Y AUDIO INPUT COMPONENT INPUT (480i/480p/720p/1080i) (R) AUDIO (L) Y Pb Pr Connect the digital set-top box video outputs to the COMPONENT (Y, PB, PR) jacks and connect the digital set-top box audio outputs to the AUDIO jacks. Viewing Setup 1. Turn on the digital set-top box.
2 Program selection 4 On screen language selection (option) Press the main power button to switch the set on. You can select a program number with the D / E or NUMBER buttons. Press the MENU button and then use D / E button to select the SPECIAL menu. If the set is in standby mode, press the POWER, D / E , INPUT SELECT, PC/DVI or NUMBER buttons on the remote control handset to switch it on fully. Press the POWER button on the remote control handset. The set reverts to standby mode.
Menu selection On screen menus - The dialog between you and your set takes place on screen with an operator menu. The buttons required for the operating steps are also displayed. 1 2 Press the MENU button and then use D / E button to display each menu. Press the G button and then use D / E button to select a menu item. 4 Press the G button to display the sub menu or the pull-down menu. Change the setting of an item in the sub or pull-down menu with F / G or D / E.
Press the MENU button and then use D / E button to select the PICTURE menu. Press the G button and then use D / E button to select PSM. Press the G button and then use D / E button to select a picture setting on the PSM pull-down menu. PICTURE PSM Contrast Brightness Color Sharpness Tint ()OO}{OOOKOOMENU Manual Picture Control Repeatedly press the MENU button to return to normal TV viewing. You can also recall a desired picture (Dynamic, Standard, Mild or User) with PSM button on the remote control.
Picture Format Picture Menu 16 : 9 Panorama 4:3 Zoom
Press the MENU button and then use D / E button to select the SOUND menu. Press the G button and then use D / E button to select SSM. Press the G button and then use D / E button to select a sound setting on the SSM pull-down menu. Repeatedly press the MENU button to return to normal TV viewing. SOUND Sound Frequency Adjustment a. Press the G button in User. b. Select a sound band by pressing the F / G button. c. Make appropriate sound level with the D / E button.
Sound Menu Balance AVL (Auto Volume Leveler) Press the MENU button and then use select the SOUND menu. D / E button to Press the MENU button and then use select the SOUND menu. D / E button to Press the G button and then use D / E button to select the desired sound item. Press the AVL. G button and then use D / E button to select Press the G button and then use appropriate adjustments. Press the G button and then use D / E button to select On or Off.
- The TV can receive MTS stereo programs and any SAP (Secondary Audio Program) that accompanies the stereo program, if the broadcaster transmits an additional sound signal as well as the original one. - Mono: The primary language is heard from left and right speakers. Signal mode is mono. - Stereo: The primary language is heard from left and right speakers. Signal mode is stereo. Sound Menu Stereo/SAP Broadcasts Setup - SAP: The secondary language is heard from left and right speakers.
Setting up TV stations Memorizing the Channels with Auto Add/Delete Channels with Manual - For Auto to work, the programming source must be connected to the TV and the TV must be receiving programming signals either over-the-air or from a cable-type service provider. - You can manually include or erase individual channels. 1. Press the MENU button and then use select the Station menu. button to 1. Press the MENU button and then use D select the Station menu. to select 2.
Favorite Channels Setup - This function adjusts the pictures stability and condition when it is poor. /E button to 1. Press the MENU button and then use D select the Station menu. D / E button to 2. Press the G button and then use select Favorite ch.. 1. Press the MENU button and then use D select the Station menu. 2. Press the G button and then use select Fine. 3. Use the F erence.
Time Menu Clock On/Off Time You must set the time correctly before using on/off time function. The off timer automatically switches the set to standby at the preset time. Press the MENU button and then D / E button to select the TIME menu. Press the G button and then D /E button to select Off Time or On Time. Press the G button and then D /E button to select On. Press the MENU button and then D /E button to select the TIME menu.
Sleep timer If you select On on the Auto Sleep menu, the set will automatically switch itself to standby mode approximately ten minutes after a TV station stops broadcasting. Press the MENU button and then D TIME menu. Press the G button and then /E D /E button to select the button to select Auto Sleep. Press the Off. G button and then D /E button to select On or Press the MENU or OK button to save.
Parental Control can be used to block specific channels, ratings and other viewing sources. The Parental Control Function (V-Chip) is used to block program viewing based on the ratings sent by the broadcast station. The default setting is to allow all programs to be viewed. Viewing can be blocked by the type of program and by the categories chosen to be blocked. It is also possible to block all program viewing for a time period. To use this function, the following must be set : 1.
Lock Menu Lock Menu Setup 1. Press the MENU button and then use Then, press the G button. D /E button to select the LOCK menu. • If Lock is already set, enter the password requested. • The TV is set with the initial password “0-0-0-0”. 2. Setting Lock on/off: Press the Use the D /E F /G button to select Lock on/off. button to select on or off. 3. Set password: Press the D /E button to select Set password. Press the G button and then enter a four digit password. Enter it again when requested. 4.
You can adjust horizontal/vertical position, clock, phase, and auto-configure, reset as you prefer. Press the MENU button and then D / E button to select the SPECIAL menu. Press the G button and then D / E button to select the desired picture item. Press the F / G button to make appropriate adjustments. H-Position / V-Position This function is to adjust picture to left/right and up/down as you prefer. Clock This function is to minimize any vertical bars or stripes visible on the screen background.
PIP (Picture-In-Picture) Feature - PIP lets you view 2 different inputs (sources) on your monitor screen at the same time. One source will be large, and the other source will show a smaller inset image. - PIP is not available in Lock On mode only. Watching PIP Press the PIP button to show the sub picture. • Each press of PIP button changes the screen display as shown below. Moving the PIP Press the PIP POSITION button. Press the PIP POSITION button repeatedly until desired position is achieved.
Press the SWAP button to exchange the main and sub pictures. Selecting a Input Signal Source for the PIP Use the PIP INPUT button to select the input source for the sub picture. Programme scan This function enables you to search all the stored stations on 4 or 12 sub pictures and see your favorite station by exchanging the main and sub pictures. Press the SCAN button repeatedly to select POP4/POP12. The selected sub or main pictures search all the stored stations.
External Control Device Setup - Connect the RS-232C input jack to an external control device (such as a computer or an A/V control system) and control the set’s functions externally. How to connect external control equipment Type of connector; D-Sub 9-pin male No.
Command Reference List Press the MENU button and then use select the SPECIAL menu. Press the G button and then use select Set ID. D D / / E E button to button to Press the G button and then use F / G button to adjust Set ID to choose the desired monitor ID number. The adjustment range of Set ID is 1 ~ 99. Use this function to specify a monitor ID number. SPECIAL Language CSM PC Control WXGA VGA Set ID Caption Caption/Text ()OO}{OOOKOOMENU COMMAND COMMAND 2 1 01. Power 02. Input Select 03.
External Control Device Setup Transmission / Receiving Protocol G To control Power On/Off of the set. Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] * [Command 1] : First command to control set. * [Command 2] * [Set ID] : To control LCD set. : You can adjust the set ID to choose desired monitor ID number in special menu. See previous page. Adjustment range is 1 ~ 99. When selecting Set ID ‘0’, every connected PDP set is controlled. : To transmit command data.
06. Volume Control (Command2 : i) G To adjust the screen format. You can also adjust the screen format using the ARC (Aspect Ratio Control) button on remote control handset. Transmission G To adjust volume. You can also adjust volume with the volume buttons on remote control handset. [k][q][ ][Set ID][ ][Data][Cr] Data 0 : 16:9 1 : 14:9 2 : 4:3 Transmission [k][i][ ][Set ID][ ][Data][Cr] 3 : Zoom 4 : Panorama Acknowledgement Data Min : 0 ~ Max : 64 • Refer to ‘Real data mapping 1’. See page 37.
External Control Device Setup 09. Color (Command2 : f) 12. Remote Control Lock Mode (Command2 : p) G To adjust the screen color. You can also adjust color in the PICTURE menu. G To lock the remote control and front panel controls on the set Transmission Transmission [k][f][ ][Set ID][ ][Data][Cr] [k][p][ ][Set ID][ ][Data][Cr] Data Min : 0 ~ Max : 64 • Refer to ‘Real data mapping 1’. See page 37.
* Real data mapping 1 G To adjust balance. You can also adjust balance in the SOUND menu. 0 : Step 0 Transmission A : Step 10 (SET ID 10) [k][j][ ][Set ID][ ][Data][Cr] Data Min: 0 ~ Max: 64 • Refer to ‘Real data mapping 1’. See page 37. Acknowledgement F : Step 15 (SET ID 15) 10 : Step 16 (SET ID 16) * Real data mapping 2 0 : -10 5 : -9 A : -8 2D: -1 32 : 0 37 : +1 64 : Step 100 5F : +9 64 : +10 [j][ ][Set ID][ ][OK][Data][x] 18. SSM (Command2 : h) 16.
External Control Device Setup 20. Auto Sleep (Command2 : n) 23. Auto Configure (Command2 : ~) G If there is no input signal, the set turn off automatically after 10 minutes. G To adjust picture position and minimize image shaking automatically. It works only in RGB (PC) mode.
G To select a programme for the main picture. Transmission [k][%][ ][Set ID][ ][Data][Cr] Data 0 : Ch Up 1 : Ch Down Acknowledgement [%][ ][Set ID][ ][OK][Data][x] 27. Programme Number input (Command2 : $) G To select a programme. Transmission [k][$][ ][Set ID][ ][Data][Cr] Data 0 : 0~125 Acknowledgement [$][ ][Set ID][ ][OK][Data][x] 28. PSM (Command2 : t) G To select picture mode.
Displayable Monitor Specification RGB Mode / DVI Mode MODE Resolution DOS 720X400 VGA SVGA 640X480 800X600 XGA 1024X768 SXGA 1152X864 WXGA 1280X768 Horizontal Frequency (KHz) Vertical Frequency (Hz) 31.469 70.08 37.927 85.03 31.500 60.00 37.500 67.00 37.861 72.80 37.500 75.00 43.269 85.00 35.156 56.25 37.879 60.31 48.077 72.18 46.875 75.00 53.674 85.06 48.363 60.00 56.476 70.06 60.023 75.02 68.677 84.99 54.348 60.05 47.700 60.00 60.150 75.
