Installation and Assembly Instructions

Table Of Contents

Step 5:

Mount HDTV to Monitor Plate

Use an assistant to carefully lift the HDTV and position it in front

of the Monitor Bracket. Hook the two Vertical Brackets onto the

top bar of the Horizontal Monitor Plate, then slowly swing the

screen down and into place against the lower bar of the plate.

Use a flat screwdriver or ¼" hex driver to lock the screen into

place by inserting two 8-32 x 1¼" screws onto the bottom of the

Vertical Bracket, and tighten firmly against the Monitor Plate.

Step 6:

Attach Marquee Assembly

Position Marquee assembly (shipped

with Showpiece Cabinet) onto the

Marquee Brackets so the bracket

rests inside the channel on the

marquee frame. Be sure the marquee

is centered above the HDTV.

Showpiece™ Stand Manual Page 8 of 8 Ver 0109 www.itsgames.com
