Showpiece Cabinet Integrated Stand
for 32" - 52" LCD HDTV
WARNINGS
• Read the entire manual before starting installation and assembly. If you have any
questions please call IT Tech Support at 847-870-7027 x121.
• Installation should only be attempted by someone with good mechanical aptitude and
understands these instructions completely.
• A qualified assistant is recommended to safely lift and position equipment.
• Use appropriate safety gear and tools to avoid injury to your equipment, yourself or
others.
• Never exceed the 100 lb (45 kg) Maximum Load Capacity.
• Make sure all screws are tightened firmly, but do not overtighten screws.
Overtightening screws can cause damage and reduce their lifespan and holding
power.
• Take care in your placement of the cabinet and stand, and avoid heavy traffic areas,
vibration and chance of impact. Damage to equipment and customers can occur
from a falling screen or tipped cabinet.
• Do not install near sources of heat, such as heating or air conditioning vents,
fireplaces, or direct sunlight.
Table of Contents
Parts Lists .........................................................................................................................3
Required Tools..................................................................................................................4
Step 1: Attach Base Beams to Showpiece Cabinet ..........................................................5
Step 2: Attach the Monitor Plate to Mounting Poles..........................................................6
Step 3: Attach Pole Assembly to Base Beams .................................................................6
Step 4: Attach Vertical & Marquee Brackets to HDTV ......................................................7
Step 5: Mount HDTV to Monitor Plate...............................................................................8
Step 6: Attach Marquee Assembly....................................................................................8
