Owner Manual

Turn the Seat Cushion (2) upside
down and align two holes on one
of the Armrests (3) with the
pre-drilled holes under the Seat
Cushion.
Attach the Armrest to the Seat
Cushion with two Bolts(10)
using the Wrench (16). Repeat
on the other side of armrest.
Align the mechanism (4) over the
pre-drilled holes underneath the
Seat (2), make sure the front of
the mechanism is facing the front
of the Seat. Attach the mechanism
to the Seat with four Bolts (10),
and tighten all bolts with the
Wrench (16).
*Be cautious as mis-threading the
bolts will damage the seat.
3
4
5
Note : No difference on left and right armrests to make fast installation.
Step 4:
Step 3:
(10)×4
(2)
(3)
(10)×4
(4)
(3)
(2)
