User Manual

PAGE 16USER MANUAL
Technical Data
Model No.: IBBQBI4B
Gas Type Universal LP Gas & Natural Gas
Universal LP Gas Natural Gas
Test Point Pressure 2.75KPA 1.0KPA
Main Burner (injector size) 0.98mm 1.50mm
Back Burner ( Injector size) 0.98mm 1.65mm
Total Nominal Gas Consumption ( MJ/h) 64.5 57
Main Burner Nominal Gas Consumption ( MJ/h) 13X4 11X4
Back Burner Nominal Gas Consumption ( MJ/h) 12.5X1 13X1
AC Adaptor Input: 230-240VAC, 50Hz
Output: 12VAC 2000mA
Cord 250V, 10A
Note:
► For Use outdoors only
► Conversion to natural gas only to be done by authorized person
► The maximum cylinder size for use with this appliance is 9kgs
► The thread type of this appliance is G1/4B-19.
► Always keep the electrical components in dry condition
