USER MANUAL I N A LTO.C O M .
USER MANUAL Residentia Group — Head Office. 118 Campbell Street Collingwood, VIC Australia 3066 — ACN. 600 546 656 — Online. residentia.group PAGE 02 Congratulations on purchasing your new BBQ. The InAlto brand is proudly distributed within Australia by Residentia Group Pty Ltd. Please refer to the warranty card at the rear of this manual for information regarding your product’s parts and labour warranty, or visit us online at www. residentia.
CONTENTS 02 04 06 08 10 YOUR INALTO BBQ INSTALL ATION INSTRUCTIONS 16 17 18 19 WELCOME CLEANING & MAINTENANCE 20 WARRANTY INFORMATION SAFET Y INSTRUCTIONS TROUBLESHOOTING U SE OUTDOORS ONLY TECHNICAL DATA PURCHASE DETAILS
USER MANUAL PAGE 04 Safety Instructions Your safety is of the utmost importance to us. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Retailer where you purchased your unit from. The appliance should only be installed and connected by a suitably qualified and authorised person, strictly in accordance with the manufacturer's instructions.
PAGE 05 INALTO.COM.AU DECLARATION OF CONFORMITY FOR OUTDOOR USE ONLY This appliance complies with the following European Directives and Australian Standards: — 2006/95/CE General regulations / Low tension — 2009/142/CE Concerning gas appliances — 1935/2004/CE 90/128/EEC This appliance is suitable to come in contact with food — 2004/108/CE Electromagnetic compatibility — AS4551, AS/NZS 5263.0, AS/NZS 5263.1.
USER MANUAL PAGE 06 Use Outdoors Only This appliance shall only be used in an above ground openair situation with natural ventilation, without stagnant areas, where gas leakage and products of combustion are rapidly dispersed by wind and natural convection. Any outdoor enclosure in which the appliance is used shall comply with one of the following: ► An enclosure with walls on all sides, but at least one permanent opening at ground level and no overhead cover. See Figure 1.
PAGE 07 INALTO.COM.AU Use Outdoors Only GAS CYLINDER INFORMATION This appliance is designed to be used with a gas cylinder not exceeding (Australia 9KG) ► The gas cylinder supply valve must be turned off when the appliance is not in use. ► Gas cylinders must be stored outdoors, out of reach of children and must not be stored in a building, garage or any other enclosed area. ► The gas cylinder used must incorporate a safety collar to protect the valve assembly.
USER MANUAL PAGE 08 Your InAlto BBQ SPECIFICATIONS IBBQBI4B BUILT IN INSTALLATION WARNING THE CONSTRUCTION OF THE ENCLOSURE AND INSTALLATION OF THE BBQ SHOULD BE CARRIED OUT ONLY BY AUTHORISED PERSONS. THE BARBECUE MUST ALSO BE SECURED TO THE ENCLOSURE TO PREVENT IT BEING PULLED OUT AND STRAINING THE GAS CONNECTIONS. ► Please follow these instructions for installation. any other requirements of AS/NZS 5601.
PAGE 09 INALTO.COM.
USER MANUAL PAGE 010 Installation Instructions ASSEMBLY INSTRUCTIONS WARNING Ensure all transit protection is removed prior to assembly. 1 Foot ( No.20)Assembly 4 Cooking grid( No.2)/plate ( No.3) assembly 5 Warming rack (No.1) assembly 2 Built in supporting bracket Assembly ( No.24.25) 3 Flame tamer ( No.4)assembly 6 Grease tray( No.
PAGE 01 1 INALTO.COM.AU 7 Battery is require for ignition Battery ( Battery is not included) 8 Transformer (for BBQ lights / LED) ► AssemblyTransformer needs to be installed and fixed where it is located well away from high temperatures. ► The transformer must be always kept dry.
USER MANUAL PAGE 12 NATURAL GAS CONVERSION WARNING 1 Conversions only to be done by an Authorized person 2 A restraining tether or bracket is required to be fixed to the appliance and to the wall within 50mm of each connection point. The length of the tether shall not exceed 80% of the length of the natural gas hose assembly.
PAGE 13 INALTO.COM.AU 4 . Reassemble the burner. （3） （4） 3. With the burner removed, you will see the brass gas jet which is screwed into the end of the valve. Using the socket driver supplied, unscrew the end LPG jet while retaining the inner (NG) jet. Note: Please make sure the gas valve is located well inside the main burner tube when re-installing the burners. 5. Repeat the above steps for the other main burners.
USER MANUAL INSTRUCTIONS FOR CONVERTING THE BACK BURNER 1. Remove the back burner cover (3) (4) 2. Remove the LPG jet from the elbow shaped brass injector assembly.
PAGE 15 INALTO.COM.AU 3. 3. disconnect the cable 4. Replace a new light and re-assemble Reassemble the plates as removed. Instruction to replace the LED light 1. Take off the control knob and unscrew the knob bezel 2. Take off the unit and disconnect the cable 3. Replace a new one and re- assemble BARBECUE LIGHT & LED WARNING Always keep the plug in dry condition. Instruction o replace the barbecue lights 1. Take off the light rear cover 2.
USER MANUAL Technical Data Model No.: Gas Type IBBQBI4B Universal LP Gas & Natural Gas Universal LP Gas Natural Gas Test Point Pressure 2.75KPA 1.0KPA Main Burner (injector size) 0.98mm 1.50mm Back Burner ( Injector size) 0.98mm 1.65mm Total Nominal Gas Consumption ( MJ/h) 64.5 57 Main Burner Nominal Gas Consumption ( MJ/h) 13X4 11X4 Back Burner Nominal Gas Consumption ( MJ/h) 12.
PAGE 17 INALTO.COM.AU Cleaning & Maintenance All cleaning and maintenance should be carried out when the barbecue is cool and with the fuel supply turned OFF at the gas cylinder after each use. DO NOT mistake brown or black accumulation of grease and smoke for paint. Interiors of gas grills are not painted at the factory (and should NEVER be painted). Apply a strong solution of detergent and water or use a grill cleaner with brush on insides of grill lid and bottom. Rinse and allow to completely air dry.
USER MANUAL PAGE 18 Troubleshooting Please read the issues below carefully and try all relevant steps. If none of this helps, please contact us on 1300 11 4357 for further advice or to schedule a technician to inspect your cooktop. Tips & Hints THE COOKTOP WON'T LIGHT THE BURNER FL AMES ARE SLOW OR YELLOW TO START THE COOKTOP IS DIRT Y AFTER COOKING Please check... That your cooktop is plugged in and there is power to the wall socket. Please check...
PAGE 19 RECEIPT INALTO.COM.AU Purchase Details For future reference, please record the following information which can be found on the rating plate and the date of purchase which can be found on your sales invoice. The rating plate of your hob is located on the underneath of the appliance. Therefore please fit the duplicate data plates or label on the outside of the cupboard to sure that the label can be easily seen during operation.
USER MANUAL PAGE 20 Warranty Information WARRANTY TERMS & CONDITIONS BBQ APPLIANCES This document sets out the terms and conditions of the product warranties for Residentia Group Appliances. It is an important document. Please keep it with your proof of purchase documents in a safe place for future reference should you require service for your Appliance. 1.
PAGE 21 INALTO.COM.AU 5. You will bear the cost of transportation, travel and delivery of the Appliance to and from Residentia Group or its ASR.
— W W W. R E S I D E N T I A .
