Dimension
Unit: mm
1709100208•
USB Cable, Length 20cm
1701090150•
COM Port Cable, Length 15cm
1709100254•
Audio Cable, Length 25cm
1702150155•
Power Cable for 2.5” SATA Hard Disk, Length 15cm
1709070500•
SATA Cable, Length 50cm
1702002010•
Big Single Row 4-pin Power Input Cable for +12V Input, Length 10cm
Optional Accessories
GENE-QM67
Part Number CPU
Fan/
Fanless
Display LVDS Storage LAN USB RS-232 RS-232/422/485 Expansion Slot Power Temp
TF-GENE-QM67-A10 Socket FAN
CRT + LVDS
CRT+DVI
LVDS+DVI
LVDS+LVDS
1st 18/24-bit, 2CH
2nd 18/24-bit, 2CH
SATA3 x 2, CFast™ x 1,
mSATA (Optional)
GbE x 2 8 3 1 Mini Card x 1 +12V, AT/ATX 0°C ~ 60°C
