REF PART NAME QTY

1 ADAPTOR PLATE 1

2 INTERFACE ARM 2

3 M5 METAL WASHER 12

4 M5 x 12mm SCREW 12

INTERFACE KIT

A M4 x 12mm SCREW 8

B M4 x 16mm SCREW 8

C M4 x 25mm SCREW 4

D M4 x 40mm SCREW 8

E M5 x 25mm SCREW 6

F M5 x 50mm SCREW 4

G M6 x 12mm SCREW 4

H M6 x 25mm SCREW 4

I M5 METAL WASHER 8

J M5 x 12mm SPACER 8

K M5 x 30mm SPACER 4

A

B

C

D E F G

G

I J K
