User guide

11
BT7505
PRODUCT DIMENSIONS
THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO
LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT.
20mm
0.8"
320mm 12.6"
570mm
22.4"MAX
170mm 6.7"
100mm
3.9"
75mm
3"
75mm 3"
100mm 3.9"
500mm
19.7"
ADAPTOR PLATE
300mm 11.8"MAX
588mm
23.1"MAX
123mm
4.8"MIN
