Data Sheet

Specifications
What’s in the box
Camera
1/3” 4 Megapixel Progressive CMOS
4MP(2560x 1440)
Night Vision: 30m(98ft) Distance
2.8mm or 3.6mm Fixed Lens
Field of View : 2.8mm:101°(H), 54°(V), 123°(D)
3.6mm: 80°(H), 44°(V), 95°(D)
Video & Audio
Notice Management
Video Compression : H.265/H.264
Up to 20fps Frame Rate
16x Digital Zoom
Built-in Mic
Motion Detection
Configurable Region
- 1x Camera
- 1x Quick Start Guide
- 1x Screw Package
- 1x Installation Position Map
Network
Wi-Fi:IEEE802.11b/g/n, 50m Open Field
CGI, ONVIF
Auxiliary Interface
Micro SD Card Slot (up to 128GB)
Reset Button
General
DC 12V1A Power Supply
Power Consumption:<4.8W
Working Environment: -30°C~+50°C, Less Than 95%RH
Dimensions: 84.6 × 70.0 × 164.6mm (3.3 × 2.8 × 6.5inch)
Weight: 260g (0.57lb)
CE, FCC, UL
http://www.imoulife.com
Rev 001.001
1 x 100Mbps Ethernet Port
Imou App: iOS, Android
IP67
- 1x Power Adapter
Material: Metal (front cover) + Plastic (body, bracket)
