Model number CI20
SoC Ingenic JZ4780
CPU Dual 1.2 GHz XBurst MIPS32
little endian
Caches 32 kl + 32 kD per core, 512K
shared L2
RAM
NAND
1 GB DDR3
8 GB
SD card 1x full size slot + 1x slot via
secondary expansion header
USB 1x USB otg + 1x USB host
Ethernet
Wi-Fi
1x 10/100 Mbps using Davicom
DM9000C controller over 8-bit
interface
IW8103 Wi-Fi + BT4.0, built-in
ceramic aerial
GPU SGX540
Video Hardware video decode up
to 1080
Display
Camera
HDMI, up to 2k resolution
ITU645 dedicated connector
GPIO 25 available on headers
SPI 2 ports on primary and secondary
expansion header, with 4 chip
selects
I2C
ADC
1 port on primary expansion
header
7 inputs on secondary expansion
header, including 5-wire touch
and battery monitoring functions
UART
Audio
1 on dedicated UART header, 2
via primary expansion header
Audio in and out via 3.5mm
4-wire connector
JTAG Standard 14-pin MIPS EJTAG
header
Transport Stream
Interface
Via secondary expansion header
Power
Rating
5V via 4 mm (shield) x 1.7 mm
(pin) centre positive connector
DC input 5V 500 mA – 1000 mA
Approvals
FCC ID: X280073, IC: 8864A-0073
