Instructions / Assembly

OWNER′S MANUAL
2
1. Before using or reusing, inspect the product carefully. Discard any products that have cut, damaged or frayed wire
insulation or cords, cracks in the lampholders or enclosures, loose connections, or exposed copper wire.
2. When not in use, store in a cool, dry location protected from sunlight.
USE & CARE INSTRUCTIONS
EXTENDER KIT SETUP INSTRUCTIONS
Mix-and-Match within the same series for Extra Fun!
This product is connectable with other Color Blast
™
Type B LED Lights. Simply calculate the Rated Wattage of all
connected products and create your own light show.
IMPORTANT: The total Rated Wattage of all connected products should not exceed the Maximum Wattage Capacity of
a single product.
SETUP INSTRUCTIONS
1. Understand your product.
2. Push the stakes into the ground (soil/lawn) at your desired spot and plug it in to the wall outlet.
Example:
(1) Max. Watt Capacity of Product A: 10W
(2) Rated Wattage of Product A: 3.1W
(3) Rated Wattage of Product B: 4.2W
Then a feasible connection can be:
A x 1 + B x 1
(3.1W) + (4.2W) = 7.3W
7.3W < 10W
Ground Stake x 3
2. Make sure connectors are fully inserted and any connector rings are twisted until completely secured such that the
rings can no longer be turned and the two portions of the connectors are completely assembled.
3. The lighting string is rated 3.1 Watts (0.62 Amps). Do not overload. Connect other COLOR BLAST™ remote controlled
LED lights (Type B) end-to-end up to a maximum of 10 Watts (2.0 Amps) total. To avoid the risk of fire or personal
injury, do not exceed the maximum allowable electrical load.
Candy Cane Pathway Marker LED Lights
Rated Wattage: 3.1W (0.62A), Total Wattage: 4.2 Watts
Maximum Wattage Capacity: 10W (2.0A)
AC Adapter
Input: 120V/60Hz, 0.16A
Output: DC 5V, 2A
Adapter
Extension cord
Controller
Add-on Connector
