Manual

6HWWLQJXSDQGSODFLQJLQVHUYLFH
IKA

-WERKE C 5000 control/duo-control Ver. 10 04.07
3DJH
:LWKFRPEXVW LRQ DLG configuration box
If the option :LWKFRPEXVWLRQDLG is marked, the values of the scale are
transferred in the following order:
1. “Weighed in combustion aid”
2. “Weighed in combustion aid + weighed in sample”
5HYHUVH configuration box
If the box UHYHUVH is marked in addition to the configuration box :LWKFRP
EXVWLRQDLG scale values will be transferred in the following order:
1. “Weighed in sample”
2. “Weighed in sample + weighed in combustion aid”
After the transfer, the second measured value appears in the “New meas-
urement” dialog box. The calculated value for extraneous energy is already
entered there.
*URVVFDORULILFYDOXHRIWKHFRPEXVW LRQ DLG configuration box
In combination with the configuration box :LWKFRP EXVWLRQDLG the gross
calorific value of the combustion aid must be entered in this box so that the
system can calculate the extraneous energy.
