7HFKQLFDOGDWD
IKA

-WERKE C 5000 control/duo-control Ver. 10 04.07
3DJH
 7HFKQLFDOGDWDIRUWKH&FRROLQJV\VWHP
Operating power see rating plate
Power consumption max. 300 Watts
Cooling output 240 Watts
Device fuses 2 x 3.0 A, FF; 230 V
2 x 6.0 A, FF; 100/115 V
Protection type according to DIN 40 050 IP 21
Protection class 1 (protective grounding)
Over-voltage category 2
Contamination level II
Ambient temperature 15°C ... 25°C
Ambient relative humidity 80 %
Dimensions 180 x 380 x 397 mm (WxDxH)
Weight 17 kg
 7HFKQLFDOGDWDIRUWKH& FRROLQJV\VWHP
Operating power see rating plate
Power consumption max. 700 Watts
Cooling output 2 x 300 Watts
Device fuses 2 x 4.0 A, FF; 230 V
2 x 8.0 A, FF; 100/115 V
Protection type according to DIN 40 050 IP 21
Protection class 1 (protective grounding)
Over-voltage category 2
Contamination level II
Ambient temperature 15°C ... 25°C
Ambient relative humidity 80 %
Dimensions 440 x 380 x 397 mm (WxDxH)
Weight 33 kg
 7HFKQLFDOGDWDIRUWKH& FRROLQJV\VWHP
Cooling-water temperature 18°C ... 20°C
Cooling-water flow rate 90 l/h ... 140 l/h
Diameter of cooling-water hoses 10 mm
For further data and operating instructions, please see Data Sheet C 5004 (included
in scope of supply).
