Manual

IKA

-WERKE C 5000 control/duo-control Ver. 10 04.07
3DJH
 7HFKQLFDOGDWD
 7HFKQLFDOGDWD IRUWKHFRQWUROOHU
Operating power electrical power is supplied through
measurement cell to conform to rating
plate
Power consumption:
C 5000 control
(controller with one measurement cell)
C 5000 duo-control
(controller with two measurement cells)
max. 1300 Watts
max. 2500 Watts
Device fuses 1 x 3.15 AT; 230 V
1 x 6.25 AT; 100/115 V
Protection type according to DIN 40 050 IP 21
Protection class 1 (protective grounding)
Over-voltage category 2
Contamination level II
Ambient temperature 20°C ... 25°C
Ambient relative humidity 80 %
Dimensions
(Controller with measurement cell, with-
out display)
560 x 380 x 397 mm (WxDxH)
Weight
(controller with measurement cell)
41 kg
Display 320 x 200 pixels, with illuminated back-
ground
 7HFKQLFDOGDWDRQWKH&PHDVXUHPHQWFHOO
Operating power see rating plate
Power consumption see controller
Device fuses 2 x 6.25 AT; 230 V
2 x 15 AT; 100/115 V
Protection type according to DIN 40 050 IP 21
Ambient temperature 15°C ... 25°C
Ambient relative humidity 80%
Dimensions 440 x 380 x 397 mm (WxDxH)
Weight 34 kg
